UEST211-35
| Part Number | UEST211-35 |
| System of Measurement | Inch |
| Bearing Part Number | UE211-35 |
| Housing Part Number | ST211 |
| Product Series | UEST200 |
| Bearing Type | Ball Bearing |
| Housing Type | Wide Slot Take-Up |
| Inner Ring Type | Wide Inner Ring |
| Seal Type | Double Sealed |
| Locking Style | Accu-Loc® Concentric Collar Locking |
| Lubrication Fitting Tap | 1/8-27 NPT |
| Bore Dia | 2-3/16" |
| Bore Dia Tolerance | -0.0005" to 0" |
| Center Height | 4-3/16" |
| Height | 6-3/4" |
| Length | 5-3/4" |
| Width | 3-3/4" |
| Pillow Height | 3/4" |
| Bearings Material | AISI 52100 Steel |
| Housing Material | Cast Iron |
| Lubrication | Required |
| Temperature Range | -30° to 110 °C |
| RoHS | Compliant |
| REACH | Compliant |
| Weight | 9.90 lb |
| e | 5-1/8" |
| J | 2-1/2" |
| k | 1-1/16" |
| L | 2-15/64" |
| o | 1" |
| p | 4" |
| q | 2-1/2" |
| s | 1-3/8" |
| x | 1-5/8" |
| Z | 2.167" |
})
