Mounted Linear Bearings for Spline Shafts
15 Products
Mounted Linear Bearings for Spline Shafts
Ready to mount on your linear motion spline shaft, these bearings come installed in a housing and have grooves that match up with the splines on your shaft.
Part Number
Bore Dia
Overall Length
Flange OD
Bolt Circle Dia
Outer Dia
With End Seals
Maximum Torque
Temperature Range
>
Part Number
Bore Dia
Overall Length
Flange OD
Bolt Circle Dia
Outer Dia
With End Seals
Maximum Torque
Temperature Range
>
GBBEFKEB
6 mm
25 mm
30 mm
22 mm
14 mm
No
13 in.-lbs.
- to 176° F
GBBEFKEC
8 mm
25 mm
32 mm
24 mm
16 mm
No
18 in.-lbs.
- to 176° F
GBBEFKED
10 mm
33 mm
42 mm
32 mm
21 mm
No
38 in.-lbs.
- to 176° F
GBBEFKBBB
13 mm
36 mm
43 mm
33 mm
24 mm
No
185 in.-lbs.
- to 176° F
GBBEFKBBC
16 mm
50 mm
50 mm
40 mm
31 mm
No
531 in.-lbs.
- to 176° F
GBBEFKEG
18.2 mm
60 mm
51 mm
40 mm
32 mm
No
734 in.-lbs.
- to 176° F
GBBEFKDDH
20 mm
40 mm
52 mm
38 mm
28 mm
No
911 in.-lbs.
- to 212° F
GBBEFKBBD
20 mm
63 mm
58 mm
45 mm
35 mm
No
929 in.-lbs.
- to 176° F
GBBEFKEH
23 mm
70 mm
60 mm
47 mm
37 mm
No
1433 in.-lbs.
- to 176° F
GBBEFKDED
25 mm
50 mm
62 mm
48 mm
34 mm
No
1902 in.-lbs.
- to 212° F
GBBEFKBBE
25 mm
71 mm
65 mm
52 mm
42 mm
No
1672 in.-lbs.
- to 176° F
GBBEFKEI
28 mm
80 mm
70 mm
54 mm
45 mm
No
2557 in.-lbs.
- to 176° F
GBBEFKBBF
30 mm
80 mm
75 mm
60 mm
47 mm
No
2716 in.-lbs.
- to 176° F
GBBEFKEJ
37.4 mm
100 mm
90 mm
72 mm
60 mm
No
5637 in.-lbs.
- to 176° F
GBBEFKBBG
40 mm
100 mm
100 mm
82 mm
64 mm
No
5964 in.-lbs.
- to 176° F
