Product Categories Gears / Spur Gears
  • Equivalent to Manufacturer :
  • Martin

Spur Gears

887 Products
Spur Gears Spur Gears Feature straight teeth, high efficiency, and reliable power transmission for parallel shaft applications.
Part Number
OD
Material
Bore Type
Gear Pitch
Diameter
Pressure
Angle
Pitch
Diameter
Hub
Diameter
Hub
Projection
Storage Dimension
Length
Storage Dimension
Width
Storage Dimension
Height
Number Of
Teeth
Face Width
S3216 14 1/2 DEG STEEL
0.563"
Steel
Plain
32
14.500°
0.500"
0.406"
0.312"
0.563"
0.563"
0.500"
16
0.188"
S2411 14 1/2 DEG STEEL
0.583"
Steel
Plain
24
14.500°
0.500"
0.375"
0.313"
0.583"
0.583"
41533.000"
11
0.25"
S2412 14 1/2 DEG STEEL
0.583"
Steel
Plain
24
14.500°
0.500"
0.375"
0.313"
0.583"
0.583"
41533.000"
12
0.25"
S2414 14 1/2 DEG STEEL
0.666"
Steel
Plain
24
14.500°
0.583"
0.469"
0.313"
0.666"
0.666"
41533.000"
14
0.25"
S2011 14 1/2 DEG STEEL
0.7"
Steel
Plain
20
14.500°
0.600"
0.469"
0.375"
0.700"
0.700"
0.750"
11
0.375"
S2011BS 5/16 14 1/2 DEG STEEL
0.7"
Steel
Bushing
20
14.500°
0.600"
0.469"
0.375"
0.700"
0.700"
0.750"
11
0.375"
S2012 14 1/2 STEEL
0.7"
Steel
Plain
20
14.500°
0.600"
0.469"
0.375"
0.700"
0.700"
0.750"
12
0.375"
S2012BS 5/16 14 1/2 DEG STEEL
0.7"
Steel
Bushing
20
14.500°
0.600"
0.469"
0.375"
0.700"
0.700"
0.750"
12
0.375"
TS2012 20 DEG STEEL
0.7"
Steel
Plain
20
20°
0.600"
0.469"
0.438"
0.700"
0.700"
0.940"
12
0.5"
TS2012BS 5/16 20 DEG STEEL BS
0.7"
Steel
Bushing
20
20°
0.600"
0.469"
0.438"
0.700"
0.700"
0.940"
12
0.5"
S2415 14 1/2 DEG STEEL
0.708"
Steel
Plain
24
14.500°
0.625"
0.5"
0.313"
0.708"
0.708"
41533.000"
15
0.25"
S2013 14 1/2 DEG STEEL
0.75"
Steel
Plain
20
14.500°
0.650"
0.5"
0.375"
0.750"
0.750"
0.750"
13
0.375"
S2013BS 5/16 14 1/2 DEG STEEL
0.75"
Steel
Bushing
20
14.500°
0.650"
0.5"
0.375"
0.750"
0.750"
0.750"
13
0.375"
S2416 14 1/2 DEG STEEL
0.75"
Steel
Plain
24
14.500°
0.666"
0.547"
0.313"
0.750"
0.750"
41533.000"
16
0.25"
S2417 14 1/2 DEG STEEL
0.791"
Steel
Plain
24
14.500°
0.709"
0.563"
0.313"
0.791"
0.791"
41533.000"
17
0.25"
S2014 14 1/2 DEG STEEL
0.8"
Steel
Plain
20
14.500°
0.700"
0.547"
0.375"
0.800"
0.800"
0.750"
14
0.375"
S2014BS 5/16 14 1/2 DEG STEEL
0.8"
Steel
Bushing
20
14.500°
0.700"
0.547"
0.375"
0.800"
0.800"
0.750"
14
0.375"
TS2014 20 DEG STEEL
0.8"
Steel
Plain
20
20°
0.700"
0.547"
0.438"
0.800"
0.800"
0.990"
14
0.5"
TS2014BS 5/16 20 DEG STEEL BS
0.8"
Steel
Bushing
20
20°
0.700"
0.547"
0.438"
0.800"
0.800"
0.690"
14
0.5"
S2418 14 1/2 DEG STEEL
0.833"
Steel
Plain
24
14.500°
0.750"
0.625"
0.313"
0.833"
0.833"
41533.000"
18
0.25"
S2015 14 1/2 STEEL
0.85"
Steel
Plain
20
14.500°
0.750"
0.609"
0.375"
0.850"
0.850"
0.750"
15
0.375"
S2015BS 3/8 14 1/2 DEG STEEL
0.85"
Steel
Bushing
20
14.500°
0.750"
0.609"
0.375"
0.850"
0.850"
0.750"
15
0.375"
TS2015 20 DEG STEEL
0.85"
Steel
Plain
20
20°
0.750"
0.609"
0.437"
0.850"
0.850"
0.940"
15
0.5"
TS2015BS 3/8 20 DEG STEEL BS
0.85"
Steel
Bushing
20
20°
0.750"
0.609"
0.437"
0.850"
0.850"
0.938"
15
0.5"
S1611 14 1/2 DEG STEEL
0.875"
Steel
Plain
16
14.500°
0.750"
0.563"
0.438"
0.875"
0.875"
0.938"
11
0.5"
S1611BS 3/8 14 1/2 DEG STEEL
0.875"
Steel
Bushing
16
14.500°
0.750"
0.563"
0.438"
0.875"
0.875"
0.938"
11
0.5"
S1612 14 1/2 DEG STEEL
0.875"
Steel
Plain
16
14.500°
0.750"
0.563"
0.438"
0.875"
0.875"
0.938"
12
0.5"
S1612BS 3/8 14 1/2 DEG STEEL
0.875"
Steel
Bushing
16
14.500°
0.750"
0.563"
0.438"
0.875"
0.875"
0.938"
12
0.5"
S2419 14 1/2 DEG STEEL
0.875"
Steel
Plain
24
14.500°
0.791"
0.625"
0.313"
0.875"
0.875"
41533.000"
19
0.25"
TS1612 20 DEG STEEL
0.875"
Steel
Plain
16
20°
0.750"
0.563"
0.500"
0.875"
0.875"
1.250"
12
0.75"
TS1612BS 3/8 20 DEG STEEL BS
0.875"
Steel
Bushing
16
20°
0.750"
0.563"
0.500"
0.875"
0.875"
1.250"
12
0.75"
S2016 14 1/2 DEG STEEL
0.9"
Steel
Plain
20
14.500°
0.800"
0.656"
0.375"
0.900"
0.900"
0.750"
16
0.375"
S2016BS 3/8 14 1/2 DEG STEEL
0.9"
Steel
Bushing
20
14.500°
0.800"
0.656"
0.375"
0.900"
0.900"
0.750"
16
0.375"
TS2016 20 DEG STEEL
0.9"
Steel
Plain
20
20°
0.800"
0.656"
0.437"
0.900"
0.900"
0.940"
16
0.5"
TS2016BS 3/8 20 DEG STEEL BS
0.9"
Steel
Bushing
20
20°
0.800"
0.656"
0.437"
0.900"
0.900"
0.938"
16
0.5"
S2420 14 1/2 DEG STEEL
0.917"
Steel
Plain
24
14.500°
0.833"
0.719"
0.313"
0.917"
0.917"
41533.000"
20
0.25"
S1613 14 1/2 DEG STEEL
0.937"
Steel
Plain
16
14.500°
0.812"
0.625"
0.438"
0.937"
0.937"
0.938"
13
0.5"
S1613BS 3/8 14 1/2 DEG STEEL
0.937"
Steel
Bushing
16
14.500°
0.812"
0.625"
0.438"
0.937"
0.937"
0.938"
13
0.5"
TS1613 20 DEG STEEL
0.937"
Steel
Plain
16
20°
0.812"
0.625"
0.500"
0.937"
0.937"
1.250"
13
0.75"
S2017 14 1/2 DEG STEEL
0.95"
Steel
Plain
20
14.500°
0.850"
0.703"
0.375"
0.950"
0.950"
0.750"
17
0.375"
S2421 14 1/2 DEG STEEL
0.959"
Steel
Plain
24
14.500°
0.875"
0.75"
0.313"
0.959"
0.959"
41533.000"
21
0.25"
S1614 14 1/2 DEG STEEL
1"
Steel
Plain
16
14.500°
0.875"
0.688"
0.438"
1.000"
1.000"
0.938"
14
0.5"
S1614BS 3/8 14 1/2 DEG STEEL
1"
Steel
Bushing
16
14.500°
0.875"
0.688"
0.438"
1.000"
1.000"
0.938"
14
0.5"
S2018 14 1/2 DEG STEEL
1"
Steel
Plain
20
14.500°
0.900"
0.75"
0.375"
1.000"
1.000"
0.750"
18
0.375"
S2018BS 3/8 14 1/2 DEG STEEL
1"
Steel
Bushing
20
14.500°
0.900"
0.75"
0.375"
1.000"
1.000"
0.750"
18
0.375"
S2422 14 1/2 DEG STEEL
1"
Steel
Plain
24
14.500°
0.917"
0.75"
0.313"
1.000"
1.000"
41533.000"
22
0.25"
S658 14 1/2 DEG STEEL
1"
Steel
Plain
6
14.500°
9.666"
4.375"
1.000"
1.000"
1.000"
2.500"
58
1.5"
C328 14 1/2 DEG CAST
1"
Cast Iron
Plain
3
14.500°
9.333"
5.235"
1.250"
1.000"
1.000"
4.250"
28
3"
C548 14 1/2 DEG CAST
1"
Cast Iron
Plain
5
14.500°
9.600"
3.735"
1.250"
1.000"
1.000"
3.000"
48
1.75"
TS1614 20 DEG STEEL
1"
Steel
Plain
16
20°
0.875"
0.688"
0.500"
1.000"
1.000"
1.250"
14
0.75"
TS1614BS 3/8 20 DEG STEEL BS
1"
Steel
Bushing
16
20°
0.875"
0.688"
0.500"
1.000"
1.000"
1.250"
14
0.75"
TS2018 20 DEG STEEL
1"
Steel
Plain
20
20°
0.900"
0.75"
0.438"
1.000"
1.000"
0.940"
18
0.5"
TS2018BS 3/8 20 DEG STEEL BS
1"
Steel
Bushing
20
20°
0.900"
0.75"
0.438"
1.000"
1.000"
0.690"
18
0.5"
S2019 14 1/2 DEG STEEL
1.05"
Steel
Plain
20
14.500°
0.950"
0.797"
0.375"
1.050"
1.050"
0.750"
19
0.375"
S1615 14 1/2 DEG STEEL
1.062"
Steel
Plain
16
14.500°
0.937"
0.75"
0.438"
1.062"
1.062"
0.938"
15
0.5"
S1615BS 1/2 14 1/2 DEG STEEL
1.062"
Steel
Bushing
16
14.500°
0.937"
0.75"
0.438"
1.062"
1.062"
0.938"
15
0.5"
TS1615 20 DEG STEEL
1.063"
Steel
Plain
16
20°
0.938"
0.75"
0.500"
1.063"
1.063"
1.250"
15
0.75"
TS1615BS 1/2 20 DEG STEEL BS
1.063"
Steel
Bushing
16
20°
0.938"
0.75"
0.500"
1.063"
1.063"
1.250"
15
0.75"
TS1615BS 3/8 20 DEG STEEL BS
1.063"
Steel
Bushing
16
20°
0.938"
0.75"
0.500"
1.063"
1.063"
1.250"
15
0.75"
S2424 14 1/2 DEG STEEL
1.083"
Steel
Plain
24
14.500°
1.000"
0.875"
0.375"
1.083"
1.083"
41402.000"
24
0.25"
S2020 14 1/2 DEG STEEL
1.1"
Steel
Plain
20
14.500°
1.000"
0.859"
0.375"
1.100"
1.100"
0.750"
20
0.375"
S2020BS 1/2 14 1/2 DEG STEEL
1.1"
Steel
Bushing
20
14.500°
1.000"
0.859"
0.375"
1.100"
1.100"
0.750"
20
0.375"
S2020BS 3/8 14 1/2 DEG STEEL
1.1"
Steel
Bushing
20
14.500°
1.000"
0.859"
0.375"
1.100"
1.100"
0.750"
20
0.375"
TS2020 20 DEG STEEL
1.1"
Steel
Plain
20
20°
1.000"
0.859"
0.438"
1.100"
1.100"
0.940"
20
0.5"
TS2020BS 1/2 20 DEG STEEL BS
1.1"
Steel
Bushing
20
20°
1.000"
0.859"
0.437"
1.100"
1.100"
0.938"
20
0.5"
S1616 14 1/2 DEG STEEL
1.125"
Steel
Plain
16
14.500°
1.000"
0.813"
0.438"
1.125"
1.125"
0.938"
16
0.5"
S1616BS 1/2 14 1/2 DEG STEEL
1.125"
Steel
Bushing
16
14.500°
1.000"
0.813"
0.438"
1.125"
1.125"
0.938"
16
0.5"
TS1616 20 DEG STEEL
1.125"
Steel
Plain
16
20°
1.000"
0.813"
0.500"
1.125"
1.125"
1.250"
16
0.75"
TS1616BS 1/2 20 DEG STEEL BS
1.125"
Steel
Bushing
16
20°
1.000"
0.813"
0.500"
1.125"
1.125"
1.250"
16
0.75"
S2021 14 1/2 DEG STEEL
1.15"
Steel
Plain
20
14.500°
1.050"
0.875"
0.375"
1.150"
1.150"
0.750"
21
0.375"
TS2021 20 DEG STEEL
1.15"
Steel
Plain
20
20°
1.050"
0.875"
0.438"
1.150"
1.150"
0.940"
21
0.5"
S2426 14 1/2 DEG STEEL
1.166"
Steel
Plain
24
14.500°
1.083"
0.875"
0.375"
1.166"
1.166"
41402.000"
26
0.25"
S1211 14 1/2 DEG STEEL
1.167"
Steel
Plain
12
14.500°
1.000"
0.75"
0.500"
1.167"
1.167"
1.250"
11
0.75"
S1211BS 1/2 14 1/2 DEG STEEL
1.167"
Steel
Bushing
12
14.500°
1.000"
0.75"
0.500"
1.167"
1.167"
1.250"
11
0.75"
S1212 14 1/2 DEG STEEL
1.167"
Steel
Plain
12
14.500°
1.000"
0.75"
0.500"
1.167"
1.167"
1.250"
12
0.75"
S1212BS 1/2 14 1/2 DEG STEEL
1.167"
Steel
Bushing
12
14.500°
1.000"
0.75"
0.500"
1.167"
1.167"
1.250"
12
0.75"
TS1212 20 DEG STEEL
1.167"
Steel
Plain
12
20°
1.000"
0.75"
0.625"
1.167"
1.167"
1.630"
12
1"
TS1212BS 1/2 20 DEG STEEL BS
1.167"
Steel
Bushing
12
20°
1.000"
0.75"
0.625"
1.167"
1.167"
1.630"
12
1"
TS1617 20 DEG STEEL
1.187"
Steel
Plain
16
20°
1.062"
0.875"
0.500"
1.187"
1.187"
1.250"
17
0.75"
S1617 14 1/2 DEG STEEL
1.188"
Steel
Plain
16
14.500°
1.063"
0.875"
0.438"
1.188"
1.188"
0.938"
17
0.5"
S2022 14 1/2 DEG STEEL
1.2"
Steel
Plain
20
14.500°
1.100"
0.969"
0.375"
1.200"
1.200"
0.750"
22
0.375"
S2022BS 3/8 14 1/2 DEG STEEL
1.2"
Steel
Bushing
20
14.500°
1.100"
0.969"
0.375"
1.200"
1.200"
0.750"
22
0.375"
TS2022 20 DEG STEEL
1.2"
Steel
Plain
20
20°
1.100"
0.969"
0.438"
1.200"
1.200"
0.940"
22
0.5"
S2427 14 1/2 DEG STEEL
1.208"
Steel
Plain
24
14.500°
1.125"
0.875"
0.375"
1.208"
1.208"
41402.000"
27
0.25"
S1213 14 1/2 DEG STEEL
1.25"
Steel
Plain
12
14.500°
1.083"
0.813"
0.500"
1.250"
1.250"
1.250"
13
0.75"
S1213BS 1/2 14 1/2 DEG STEEL
1.25"
Steel
Bushing
12
14.500°
1.083"
0.813"
0.500"
1.250"
1.250"
1.250"
13
0.75"
S1618 14 1/2 DEG STEEL
1.25"
Steel
Plain
16
14.500°
1.125"
0.938"
0.438"
1.250"
1.250"
0.938"
18
0.5"
S1618BS 1/2 14 1/2 DEG STEEL
1.25"
Steel
Bushing
16
14.500°
1.125"
0.938"
0.438"
1.250"
1.250"
0.938"
18
0.5"
S2023 14 1/2 DEG STEEL
1.25"
Steel
Plain
20
14.500°
1.150"
0.969"
0.375"
1.250"
1.250"
0.750"
23
0.375"
S2428 14 1/2 DEG STEEL
1.25"
Steel
Plain
24
14.500°
1.166"
1"
0.375"
1.250"
1.250"
41402.000"
28
0.25"
TS1213 20 DEG STEEL
1.25"
Steel
Plain
12
20°
1.083"
0.813"
0.625"
1.250"
1.250"
1.630"
13
1"
TS1213BS 5/8 20 DEG STEEL BS
1.25"
Steel
Bushing
12
20°
1.083"
0.813"
0.625"
1.250"
1.250"
1.630"
13
1"
TS1618 20 DEG STEEL
1.25"
Steel
Plain
16
20°
1.125"
0.938"
0.500"
1.250"
1.250"
1.250"
18
0.75"
TS1618BS 1/2 20 DEG STEEL BS
1.25"
Steel
Bushing
16
20°
1.125"
0.938"
0.500"
1.250"
1.250"
1.250"
18
0.75"
S2024 14 1/2 DEG STEEL
1.3"
Steel
Plain
20
14.500°
1.200"
1.063"
0.375"
1.300"
1.300"
0.750"
24
0.375"
S2024BS 1/2 14 1/2 DEG STEEL
1.3"
Steel
Bushing
20
14.500°
1.200"
1.063"
0.375"
1.300"
1.300"
0.750"
24
0.375"
S2024BS 3/8 14 1/2 DEG STEEL
1.3"
Steel
Bushing
20
14.500°
1.200"
1.063"
0.375"
1.300"
1.300"
0.750"
24
0.375"
TS2024 20 DEG STEEL
1.3"
Steel
Plain
20
20°
1.200"
1.063"
0.438"
1.300"
1.300"
0.940"
24
0.5"
TS2024BS 1/2 20 DEG STEEL BS
1.3"
Steel
Bushing
20
20°
1.200"
1.063"
0.437"
1.300"
1.300"
0.938"
24
0.5"
S1619 14 1/2 DEG STEEL
1.312"
Steel
Plain
16
14.500°
1.187"
1"
0.438"
1.312"
1.312"
0.938"
19
0.5"
logo
linkedin youtube

Email:

Address: Room 301, 6st Block, #525 Yuanjiang Road, Minhang District, Shanghai, China

Creating value for customers is our core. Using this concept when serving customers, we will considering from the perspective of customers, rather than simply selling products. We provide customers with advanced services such as designing, model selection, pre-sales and after-sales services, using our professional knowledge and experiences in bearing industry over 20 years.

Quick Links

© 2024 Lily Bearing • All Rights Reserved
loading..
