97071A103
Per Pack of 5
Bulk orders will be discounted, please contact our sales for a bulk quote.We will ship your order via FedEx within 3-5 working days after you complete the payment and the related information will be sent to your email.
Searching for the best price?
Complete the inquiry form, and we'll provide you with the most suitable solution.
Need bulk industrial price?
Submit your volume requirements, and we'll provide a tailored quote for your scale.
| Part Number | JHAHBABAD |
| System of Measurement | Metric |
| Material | Black Corrosion-Resistant-Coated Steel |
| Fastener Strength Grade/Class | Class 8 |
| Thread Size | M8 |
| Thread Pitch | 1.25 mm |
| Thread Thread Type | Metric |
| Thread Spacing | Coarse |
| Thread Fit | Class 6H |
| Thread Direction | Right Hand |
| Width | 13 mm |
| Height | 11.1 mm |
| Flange Diameter | 17.9 mm |
| Flange Thickness | 1.2 mm |
| Insert Maximum Temperature | 250° F |
| Specifications Met | DIN 6926 |
| Drive Style | External Hex |
| Nut Type | Flange, Locknut, Hex |
| Hex Nut Profile | Standard |
| Locking Type | Nylon Insert |
| RoHS | RoHS 3 (2015/863/EU) Compliant |
| REACH | REACH (EC 1907/2006) (06/14/2023, 235 SVHC) Compliant |
| Country of Origin | China |
