| Part Number | EEGIFKBF |
| System of Measurement | Inch |
| Shape | Straight |
| Type | Flange, Adapter |
| Material | 304/304L Stainless Steel |
| Pressure Class | 150 |
| Fabrication | Forged |
| Connection Type | Pipe |
| Connection Style | Threaded × Flanged |
| Thread Type | NPT |
| Gender | Female |
| Pipe Size | 1 1/2 |
| Flanged Connection Surface | Raised |
| Flange OD | 5" |
| For Bolt Diameter | 0.5" |
| Bolt Hole Diameter | 0.625000" |
| Bolt Hole Number of | 4 |
| Bolt Circle Diameter | 3.875000" |
| Maximum Pressure | 230 psi @ 72° F |
| Maximum Steam Pressure | 150 psi @ 360° F |
| For Fitting Class | 150 |
| For Fitting Material | 304 Stainless Steel, 304/304L Stainless Steel |
| For Pipe Schedule | 40 |
| For Pipe Material | 304 Stainless Steel, 304/304L Stainless Steel |
| Specifications Met | ASME B16.5, ASTM A182 |
| Weight | 3.27 lbs |
| RoHS | RoHS 3 (2015/863/EU) Compliant |
| REACH | REACH (EC 1907/2006) (06/10/2022, 224 SVHC) Compliant |
| For Use With | Air, Natural Gas, Oil, Steam, Water |
