E100B24
Bulk orders will be discounted, please contact our sales for a bulk quote.
We will ship your order via FedEx within 3-5 working days after you complete the payment and the related information will be sent to your email.
Searching for the best price?
Complete the inquiry form, and we'll provide you with the most suitable solution.
Need bulk industrial price?
Submit your volume requirements, and we'll provide a tailored quote for your scale.
Overview |
|
| Part Number | E100B24 |
Brand: LILY  |
Interchangeable With: Martin |
Characteristics |
|
| System of Measurement | Inch |
| Number Of Teeth | 24 |
| For Roller Chain Trade Size | 100-3 |
| Type | B |
Dimensions |
|
| Bore Dia | 1.125" |
| OD | 10.25" |
| Bore Max | 3.75" |
| Chain Pitch | 1.25" |
| Hub Dia | 5.75" |
| Hub Length Thru | 4.75" |
Material |
|
| Material | Steel |
Properties |
|
| WT.lb(APPROX) | 69 lbs |
Design Features of E100B24 Sprockets
E100B24 has a 1.250-inch (31.75 mm) pitch and is designed for heavy-duty power transmission. It is manufactured to ANSI standards for compatibility with standard sprockets and industrial equipment, using high-strength, heat-treated steel for durability and wear resistance. Precisely machined rollers and bushings ensure smooth operation and reduced friction, making it suitable for heavy machinery, conveyors, and other demanding drive systems.
What Benefits Can E100B24 Sprockets Provide?
- High Load Capacity: With a robust 1.250-inch pitch and heavy-duty design, it can handle substantial loads in demanding applications.
- Long Service Life: Heat-treated steel construction offers excellent durability and resistance to wear.
- Smooth and Efficient Operation: Precision-machined rollers and bushings minimize friction for consistent performance.
- Easy Compatibility: Built to ANSI standards for seamless integration with standard sprockets.
What Can E100B24 Sprockets Be Used for?
- Heavy Machinery: Ideal for transmitting power in large-scale industrial machines.
- Conveyor Systems: Well-suited for heavy-duty conveyors requiring consistent and reliable motion.
- Agricultural Equipment: Used in robust farming machinery that operates under high load conditions.
- Construction Equipment: Applicable in equipment such as cranes, hoists, and other load-bearing systems.
