UCST209-28NPMZ2
Bulk orders will be discounted, please contact our sales for a bulk quote.
We will ship your order via FedEx within 3-5 working days after you complete the payment and the related information will be sent to your email.
Searching for the best price?
Complete the inquiry form, and we'll provide you with the most suitable solution.
Need bulk industrial price?
Submit your volume requirements, and we'll provide a tailored quote for your scale.
Overview |
|
| Part Number | UCST209-28NPMZ2 |
Brand: LILY  |
Interchangeable With: AMI |
| Bearing Part Number | UC209-28MZ2 |
| Housing Part Number | ST209NP |
Characteristics |
|
| System of Measurement | Inch |
| Bearing Type | Ball Bearing |
| Bearing Seal Type | Double Sealed |
| Inner Ring Type | Wide Inner Ring |
| Mounted Type | Take-Up Bearing Units |
| Shaft Mount Type | Set Screw Locking |
| Product Series | UCST200NPMZ2 |
| Lubrication Fitting Tap | 1/8-27 NPT |
Dimensions |
|
| Bore Dia | 1.75" |
| Bore Dia Tolerance | -0.0005" to 0" |
| Overall Height | 1.875" |
| Pillow Height | 0.625" |
| Housing Height | 1.375" |
| Housing Thread | 1.125" |
| Whole Width | 4.625" |
| Whole Length | 5.6875" |
| Center Height | 3.4375" |
| Width with Locking | 1.937" |
| Width of Piloting Groove | 0.6875" |
| Width of Attachment End | 3.25" |
| Distance Between Bottoms of Piloting Grooves | 4" |
| Dia of Attachment Bolt Hole | 1.9375" |
| Length of Location Slot | 3.25" |
| Length of Attachment Slot | 0.75" |
Material |
|
| Bearings Material | AISI 52100 Steel |
| Housing Material | Iron |
Performance |
|
| Temperature Range | -30° to 110 °C |
Properties |
|
| RoHS | Compliant |
| REACH | Compliant |
| Lubrication | Required |
| Weight | 5.09 lbs |
Design Features of UCST209-28NPMZ2 Bearing
UCST209-28NPMZ2 feature a robust bearing housing mounted on a sliding or adjustable frame, allowing the take-up bearing to move along a guide to maintain proper tension in belts, chains, or conveyors. The design typically includes sealed bearing inserts for protection against contaminants and durable materials to withstand continuous load and movement. Adjustable and self-aligning features ensure reliable operation, accurate alignment, and extended service life in dynamic industrial applications.
What Benefits Can UCST209-28NPMZ2 Bearing Provide?
- Automatic or Adjustable Tensioning: They maintain proper tension in belts, chains, or conveyors, reducing slippage and improving operational efficiency.
- Enhanced Shaft Support: The bearing housing provides stable support for moving or sliding shafts under continuous load.
- Contamination Resistance: Sealed bearing inserts protect against dust, moisture, and debris, extending service life.
- Easy Installation and Adjustment: The sliding or adjustable frame allows quick setup and fine-tuning without disassembling machinery.
- Reliable Performance in Dynamic Applications: Designed to accommodate movement and misalignment, ensuring consistent operation in conveyors, material handling, and other industrial systems.
What Can UCST209-28NPMZ2 Bearing Be Used for?
- Conveyor Systems: They maintain proper tension in belt and roller conveyors, ensuring smooth and efficient material transport.
- Material Handling Equipment: Applied in systems where chain, rope, or belt tension must be adjusted dynamically for reliable operation.
- Mining and Bulk Processing Machinery: Used in feeders, crushers, and screens to maintain consistent drive tension under heavy loads.
- Agricultural and Food Processing Equipment: Support belts or chains in harvesters, conveyors, and packaging machinery where variable tension is required.
- Industrial Fans and Mechanical Drives: Provide stable support and tensioning for overhung shafts or belt-driven systems in dynamic industrial environments.
