LR5205-X-2Z-TVH-XL
| Part Number | LR5205-X-2Z-TVH-XL |
Brand: LILY  | |
Equivalent: Schaeffler (INA) |
| System of Measurement | Metric |
| Roller Shape | Cylindrical |
| Internal Construction | Ball Bearing |
| Type | Yoke Type |
| Seal Type | Shielded |
| Roller Style | Yoke Type |
| Roller Material | Bearing Steel |
| Roller Dia | 62 mm |
| Roller Width | 20.6 mm |
| Yoke Bore Dia | 25 mm |
| Max Speed | 6500 1/min |
| Static Radial Load | 15800 N |
| Dynamic Radial Load | 19600 N |
| R | 500 mm |
| rmin | 1 mm |
| Fatigue Load Limit Radial | 810 N |
| RoHS | Compliant |
| REACH | Compliant |
| Weight (g) | 0.34 kg |
})
