Needle Roller Thrust Bearings (Washers)
136 Products
Needle roller cages require ground and hardened surfaces as raceways, have a low axial section height and can support axial forces in one direction.Washers allow you to use the bearing on unhardened and unground surfaces.
Part Number
Bore Dia
Outer Dia
Thickness
Material
Temperature
Range
Range
Weight
TWA411
0.25"
0.688"
0.032"
Steel
-30° to 110 °C
1 g
TWB411
0.25"
0.688"
0.063"
Steel
-30° to 110 °C
3 g
TWC411
0.25"
0.688"
0.092"
Steel
-30° to 110 °C
4 g
TWD411
0.25"
0.688"
0.126"
Steel
-30° to 110 °C
5 g
TWA512
0.3125"
0.75"
0.032"
Steel
-30° to 110 °C
1 g
TWB512
0.3125"
0.75"
0.063"
Steel
-30° to 110 °C
3 g
TWC512
0.3125"
0.75"
0.092"
Steel
-30° to 110 °C
4 g
TWD512
0.3125"
0.75"
0.126"
Steel
-30° to 110 °C
6 g
TWA613
0.375"
0.813"
0.032"
Steel
-30° to 110 °C
1 g
TWB613
0.375"
0.813"
0.063"
Steel
-30° to 110 °C
3 g
TWC613
0.375"
0.813"
0.092"
Steel
-30° to 110 °C
5 g
TWD613
0.375"
0.813"
0.126"
Steel
-30° to 110 °C
7 g
TWA812
0.5"
0.75"
0.032"
Steel
-30° to 110 °C
1 g
TWA815
0.5"
0.938"
0.032"
Steel
-30° to 110 °C
2 g
TWB815
0.5"
0.938"
0.063"
Steel
-30° to 110 °C
4 g
TWC815
0.5"
0.938"
0.092"
Steel
-30° to 110 °C
6 g
TWD815
0.5"
0.938"
0.126"
Steel
-30° to 110 °C
8 g
TWD916
0.5625"
1"
0.126"
Steel
-30° to 110 °C
9 g
TWA1018
0.625"
1.125"
0.032"
Steel
-30° to 110 °C
3 g
TWB1018
0.625"
1.125"
0.063"
Steel
-30° to 110 °C
8 g
TWC1018
0.625"
1.125"
0.092"
Steel
-30° to 110 °C
8 g
TWD1018
0.625"
1.125"
0.126"
Steel
-30° to 110 °C
11 g
TWA1220
0.75"
1.25"
0.032"
Steel
-30° to 110 °C
3 g
TWB1220
0.75"
1.25"
0.063"
Steel
-30° to 110 °C
6 g
TWC1220
0.75"
1.25"
0.092"
Steel
-30° to 110 °C
9 g
TWD1220
0.75"
1.25"
0.126"
Steel
-30° to 110 °C
13 g
TWA1423
0.875"
1.438"
0.032"
Steel
-30° to 110 °C
4 g
TWA1427
0.875"
1.688"
0.032"
Steel
-30° to 110 °C
6 g
TWB1423
0.875"
1.438"
0.063"
Steel
-30° to 110 °C
8 g
TWB1427
0.875"
1.688"
0.063"
Steel
-30° to 110 °C
13 g
TWC1423
0.875"
1.438"
0.092"
Steel
-30° to 110 °C
12 g
TWC1427
0.875"
1.688"
0.092"
Steel
-30° to 110 °C
19 g
TWD1423
0.875"
1.438"
0.126"
Steel
-30° to 110 °C
17 g
TWD1427
0.875"
1.688"
0.126"
Steel
-30° to 110 °C
26 g
TWA1625
1"
1.563"
0.032"
Steel
-30° to 110 °C
4 g
TWB1625
1"
1.563"
0.063"
Steel
-30° to 110 °C
9 g
TWC1625
1"
1.563"
0.092"
Steel
-30° to 110 °C
13 g
TWD1625
1"
1.563"
0.126"
Steel
-30° to 110 °C
18 g
TWA1828
1.125"
1.75"
0.032"
Steel
-30° to 110 °C
5 g
TWB1828
1.125"
1.75"
0.063"
Steel
-30° to 110 °C
11 g
TWC1828
1.125"
1.75"
0.092"
Steel
-30° to 110 °C
17 g
TWD1828
1.125"
1.75"
0.126"
Steel
-30° to 110 °C
23 g
TWA2031
1.25"
1.938"
0.032"
Steel
-30° to 110 °C
6 g
TWB2031
1.25"
1.938"
0.063"
Steel
-30° to 110 °C
14 g
TWC2031
1.25"
1.938"
0.092"
Steel
-30° to 110 °C
20 g
TWD2031
1.25"
1.938"
0.126"
Steel
-30° to 110 °C
28 g
TWA2233
1.375"
2.063"
0.032"
Steel
-30° to 110 °C
7 g
TWB2233
1.375"
2.063"
0.063"
Steel
-30° to 110 °C
15 g
TWC2233
1.375"
2.063"
0.092"
Steel
-30° to 110 °C
22 g
TWD2233
1.375"
2.063"
0.126"
Steel
-30° to 110 °C
30 g
TWA2435
1.5"
2.188"
0.032"
Steel
-30° to 110 °C
8 g
TWB2435
1.5"
2.188"
0.063"
Steel
-30° to 110 °C
16 g
TWC2435
1.5"
2.188"
0.092"
Steel
-30° to 110 °C
24 g
TWD2435
1.5"
2.188"
0.126"
Steel
-30° to 110 °C
32 g
TWA2840
1.75"
2.5"
0.032"
Steel
-30° to 110 °C
9 g
TWB2840
1.75"
2.5"
0.063"
Steel
-30° to 110 °C
20 g
TWC2840
1.75"
2.5"
0.092"
Steel
-30° to 110 °C
30 g
TWD2840
1.75"
2.5"
0.126"
Steel
-30° to 110 °C
40 g
TWA3244
2"
2.75"
0.032"
Steel
-30° to 110 °C
11 g
TWB3244
2"
2.75"
0.063"
Steel
-30° to 110 °C
23 g
TWC3244
2"
2.75"
0.092"
Steel
-30° to 110 °C
33 g
TWD3244
2"
2.75"
0.126"
Steel
-30° to 110 °C
45 g
TWA3446
2.125"
2.875"
0.032"
Steel
-30° to 110 °C
11 g
TWB3446
2.125"
2.875"
0.063"
Steel
-30° to 110 °C
24 g
TWC3446
2.125"
2.875"
0.092"
Steel
-30° to 110 °C
35 g
TWD3446
2.125"
2.875"
0.126"
Steel
-30° to 110 °C
48 g
TWA3648
2.25"
3"
0.032"
Steel
-30° to 110 °C
12 g
TWB3648
2.25"
3"
0.063"
Steel
-30° to 110 °C
25 g
TWC3648
2.25"
3"
0.092"
Steel
-30° to 110 °C
37 g
TWD3648
2.25"
3"
0.126"
Steel
-30° to 110 °C
50 g
TWA4052
2.5"
3.25"
0.032"
Steel
-30° to 110 °C
13 g
TWB4052
2.5"
3.25"
0.063"
Steel
-30° to 110 °C
27 g
TWC4052
2.5"
3.25"
0.092"
Steel
-30° to 110 °C
40 g
TWD4052
2.5"
3.25"
0.126"
Steel
-30° to 110 °C
55 g
TWA4458
2.75"
3.625"
0.032"
Steel
-30° to 110 °C
17 g
TWB4458
2.75"
3.625"
0.063"
Steel
-30° to 110 °C
35 g
TWC4458
2.75"
3.625"
0.092"
Steel
-30° to 110 °C
52 g
TWD4458
2.75"
3.625"
0.126"
Steel
-30° to 110 °C
71 g
TWA4860
3"
3.75"
0.032"
Steel
-30° to 110 °C
15 g
TWB4860
3"
3.75"
0.063"
Steel
-30° to 110 °C
32 g
TWC4860
3"
3.75"
0.092"
Steel
-30° to 110 °C
47 g
TWD4860
3"
3.75"
0.126"
Steel
-30° to 110 °C
64 g
AS0414
4 mm
14 mm
1 mm
Steel
-30° to 110 °C
1 g
AS0515
5 mm
15 mm
1 mm
Steel
-30° to 110 °C
1 g
AS0619
6 mm
19 mm
1 mm
Steel
-30° to 110 °C
2 g
AS0821
8 mm
21 mm
1 mm
Steel
-30° to 110 °C
2 g
AS1024
10 mm
24 mm
1 mm
Steel
-30° to 110 °C
3 g
AS1226
12 mm
26 mm
1 mm
Steel
-30° to 110 °C
3 g
AS1528
15 mm
28 mm
1 mm
Steel
-30° to 110 °C
3 g
LS1528
15 mm
28 mm
2.75 mm
Steel
-30° to 110 °C
8 g
AS1730
17 mm
30 mm
1 mm
Steel
-30° to 110 °C
4 g
LS1730
17 mm
30 mm
2.75 mm
Steel
-30° to 110 °C
9 g
AS2035
20 mm
35 mm
1 mm
Steel
-30° to 110 °C
5 g
LS2035
20 mm
35 mm
2.75 mm
Steel
-30° to 110 °C
12 g
AS2542
25 mm
42 mm
1 mm
Steel
-30° to 110 °C
7 g
LS2542
25 mm
42 mm
3 mm
Steel
-30° to 110 °C
19 g
AS3047
30 mm
47 mm
1 mm
Steel
-30° to 110 °C
8 g
LS3047
30 mm
47 mm
3 mm
Steel
-30° to 110 °C
20 g
AS3552
35 mm
52 mm
1 mm
Steel
-30° to 110 °C
9 g
LS3552
35 mm
52 mm
3.5 mm
Steel
-30° to 110 °C
27 g
