Overview |
|
| Part Number | T1750-90010 |
Characteristics |
|
| System of Measurement | Inch |
| Bearing Type | Roller |
| Roller Bearing Type | Tapered |
| Type | Bearing |
| Seal Type | Open |
| For Load Direction | Thrust |
| Series | TTHD |
| ABEC Rating | ABEC-1 |
| Configuration | Thrust TTHD - with cage |
Dimensions |
|
| Bore Dia | 1.75" |
| Bore Dia Tolerance | +0.001" to 0 |
| Outer Dia | 3.336" |
| Outer Dia Tolerance | +0.001" to 0 |
| Width | 0.7188" |
| Width Tolerance | +0.0150" to -0.0150 |
| Fillet Radius Shaft | 0.09" |
| Fillet Radius Housing | 0.09" |
Material |
|
| Ring Material | Chrome Steel |
| Roller Material | Chrome Steel |
| Cage Material | Steel |
Performance |
|
| Dynamic Thrust Load | 9460 lbf |
| Static Thrust Load | 97700 lbf |
| Temperature Range | -30° to 110 °C |
Properties |
|
| Lubrication | Required |
| RoHS | Compliant |
| REACH | Compliant |
| Weight | 0.5 kg |
Design Features of T1750-90010 Bearing
T1750-90010 bearing features a tapered roller design with a high load capacity, allowing it to effectively handle both radial and axial loads. T1750-90010 outer dia is 3.336". Its bore dia is 1.75". Its robust construction and precise geometry ensure stability and durability, making it suitable for heavy-duty applications.
What Benefits Can T1750-90010 Bearing Provide?
- High Load Capacity: It effectively supports heavy radial and axial loads, making it suitable for demanding applications.
- Enhanced Durability: Its robust design and materials ensure a longer lifespan and reduced maintenance needs.
- Improved Stability: The tapered roller design provides excellent stability and minimizes deflection under load.
- Precision Performance: It offers precise alignment and smooth operation, enhancing overall machinery efficiency.
What Can T1750-90010 Bearing Be Used for?
- Heavy Machinery: Ideal for construction equipment like excavators, bulldozers, and cranes, where high load capacity is essential.
- Automotive: Commonly found in wheel hubs, transmissions, and differentials, supporting heavy loads and ensuring smooth operation.
- Industrial Equipment: Used in gearboxes, conveyor systems, and other machinery that requires reliability and stability.
- Mining Equipment: Suitable for harsh environments, providing durability and performance under extreme conditions.
- Agricultural Machinery: Utilized in tractors and harvesters to handle heavy-duty applications.
