High-Pressure Stainless Steel Threaded Pipe Flanges

34 Products
High-Pressure Stainless Steel Threaded Pipe Flanges High-Pressure Stainless Steel Threaded Pipe Flanges
Part Number
Pipe Size
Thread Type
Dash Size
Flange OD
Flanged Connection Surface
For Bolt Diameter
Bolt Hole Diameter
Bolt Hole Number of
Bolt Circle Diameter
Maximum Pressure
Maximum Steam Pressure
Material
Price
>
Part Number
Pipe Size
Thread Type
Dash Size
Flange OD
Flanged Connection Surface
For Bolt Diameter
Bolt Hole Diameter
Bolt Hole Number of
Bolt Circle Diameter
Maximum Pressure
Maximum Steam Pressure
Material
Price
>
HJHHKBF
1 1/2
NPT
24
0.020833"
Raised
0.75"
0.88"
4
4.5"
600 psi @ 72° F
300 psi @ 300° F
304/304L Stainless Steel
$34.11
HEGJTDF
1 1/2
NPT
24
0.020833"
Raised
0.75"
0.88"
4
4.5"
600 psi @ 72° F
300 psi @ 300° F
316/316L Stainless Steel
$102.98
BEEBNCJ
1 1/2
NPT
24
0.020833"
Raised
0.75"
0.88"
4
4.5"
1,200 psi @ 72° F
840 psi @ 400° F
304/304L Stainless Steel
$102.75
BFABNCF
1 1/2
NPT
24
0.020833"
Raised
0.75"
0.88"
4
4.5"
1,200 psi @ 72° F
840 psi @ 400° F
316/316L Stainless Steel
$105.38
HEGJTDI
3
NPT
48
0.031250"
Raised
0.75"
0.88"
8
0.104167"
600 psi @ 72° F
300 psi @ 300° F
316/316L Stainless Steel
$201.65
HJHHKBI
3
NPT
48
0.031250"
Raised
0.75"
0.88"
8
0.104167"
600 psi @ 72° F
300 psi @ 300° F
304/304L Stainless Steel
$73.96
BFABNCI
3
NPT
48
0.031250"
Raised
0.75"
0.88"
8
0.104167"
1,200 psi @ 72° F
840 psi @ 400° F
316/316L Stainless Steel
$219.94
BEEBNDD
3
NPT
48
0.031250"
Raised
0.75"
0.88"
8
0.104167"
1,200 psi @ 72° F
840 psi @ 400° F
304/304L Stainless Steel
$159.41
HJHHKBE
1 1/4
NPT
20
0.05"
Raised
0.625000"
0.75"
4
3.875000"
600 psi @ 72° F
300 psi @ 300° F
304/304L Stainless Steel
$31.52
BFABNCE
1 1/4
NPT
20
0.05"
Raised
0.625000"
0.75"
4
3.875000"
1,200 psi @ 72° F
840 psi @ 400° F
316/316L Stainless Steel
$125.84
HEGJTDE
1 1/4
NPT
20
0.05"
Raised
0.625000"
0.75"
4
3.875000"
600 psi @ 72° F
300 psi @ 300° F
316/316L Stainless Steel
$83.90
BEEBNCI
1 1/4
NPT
20
0.05"
Raised
0.625000"
0.75"
4
3.875000"
1,200 psi @ 72° F
840 psi @ 400° F
304/304L Stainless Steel
$116.58
BEEBNDC
2 1/2
NPT
40
0.071429"
Raised
0.75"
0.88"
8
0.175000"
1,200 psi @ 72° F
840 psi @ 400° F
304/304L Stainless Steel
$170.96
HJHHKBH
2 1/2
NPT
40
0.071429"
Raised
0.75"
0.88"
8
0.175000"
600 psi @ 72° F
300 psi @ 300° F
304/304L Stainless Steel
$71.89
HEGJTDH
2 1/2
NPT
40
0.071429"
Raised
0.75"
0.88"
8
0.175000"
600 psi @ 72° F
300 psi @ 300° F
316/316L Stainless Steel
$196.08
BEEBNDE
4
NPT
64
0.075000"
Raised
0.875000"
1"
8
0.062500"
1,200 psi @ 72° F
840 psi @ 400° F
304/304L Stainless Steel
$330.44
HJHHKBD
1
NPT
16
0.218750"
Raised
0.625000"
0.75"
4
0.166667"
600 psi @ 72° F
300 psi @ 300° F
304/304L Stainless Steel
$33.75
BEEBNCH
1
NPT
16
0.218750"
Raised
0.625000"
0.75"
4
0.166667"
1,200 psi @ 72° F
840 psi @ 400° F
304/304L Stainless Steel
$73.28
BFABNCD
1
NPT
16
0.218750"
Raised
0.625000"
0.75"
4
0.166667"
1,200 psi @ 72° F
840 psi @ 400° F
316/316L Stainless Steel
$79.32
HEGJTDD
1
NPT
16
0.218750"
Raised
0.625000"
0.75"
4
0.166667"
600 psi @ 72° F
300 psi @ 300° F
316/316L Stainless Steel
$61.59
HEGJTDB
1/2
NPT
08
0.25"
Raised
0.5"
0.62"
4
0.312500"
600 psi @ 72° F
300 psi @ 300° F
316/316L Stainless Steel
$49.47
HJHHKBB
1/2
NPT
08
0.25"
Raised
0.5"
0.62"
4
0.312500"
600 psi @ 72° F
300 psi @ 300° F
304/304L Stainless Steel
$27.72
BEEBNCF
1/2
NPT
08
0.25"
Raised
0.5"
0.62"
4
0.312500"
1,200 psi @ 72° F
840 psi @ 400° F
304/304L Stainless Steel
$55.23
BFABNCB
1/2
NPT
08
0.25"
Raised
0.5"
0.62"
4
0.312500"
1,200 psi @ 72° F
840 psi @ 400° F
316/316L Stainless Steel
$63.55
BEEBNCG
3/4
NPT
12
4.375000"
Raised
0.625000"
0.75"
4
3.25"
1,200 psi @ 72° F
840 psi @ 400° F
304/304L Stainless Steel
$59.26
BFABNCC
3/4
NPT
12
4.375000"
Raised
0.625000"
0.75"
4
3.25"
1,200 psi @ 72° F
840 psi @ 400° F
316/316L Stainless Steel
$68.03
HEGJTDC
3/4
NPT
12
4.375000"
Raised
0.625000"
0.75"
4
3.25"
600 psi @ 72° F
300 psi @ 300° F
316/316L Stainless Steel
$53.89
HJHHKBC
3/4
NPT
12
4.375000"
Raised
0.625000"
0.75"
4
3.25"
600 psi @ 72° F
300 psi @ 300° F
304/304L Stainless Steel
$28.67
HEGJTDG
2
NPT
32
6.5"
Raised
0.625000"
0.75"
8
5"
600 psi @ 72° F
300 psi @ 300° F
316/316L Stainless Steel
$108.96
HJHHKBG
2
NPT
32
6.5"
Raised
0.625000"
0.75"
8
5"
600 psi @ 72° F
300 psi @ 300° F
304/304L Stainless Steel
$43.16
BFABNCG
2
NPT
32
6.5"
Raised
0.625000"
0.75"
8
5"
1,200 psi @ 72° F
840 psi @ 400° F
316/316L Stainless Steel
$112.06
BEEBNDB
2
NPT
32
6.5"
Raised
0.625000"
0.75"
8
5"
1,200 psi @ 72° F
840 psi @ 400° F
304/304L Stainless Steel
$107.16
HJHHKBJ
4
NPT
64
10"
Raised
0.75"
0.875000"
8
0.125000"
600 psi @ 72° F
300 psi @ 300° F
304/304L Stainless Steel
$96.56
HEGJTDJ
4
NPT
64
10"
Raised
0.75"
0.875000"
8
0.125000"
600 psi @ 72° F
300 psi @ 300° F
316/316L Stainless Steel
$250.77
