High-Pressure Steel Threaded Pipe Flanges
8 Products
High-Pressure Steel Threaded Pipe Flanges
Part Number
Pipe Size
Thread Type
Dash Size
Flange OD
Flanged Connection Surface
For Bolt Diameter
Bolt Hole Diameter
Bolt Hole Number of
Bolt Circle Diameter
Maximum Pressure
Maximum Steam Pressure
Material
Price
>
Part Number
Pipe Size
Thread Type
Dash Size
Flange OD
Flanged Connection Surface
For Bolt Diameter
Bolt Hole Diameter
Bolt Hole Number of
Bolt Circle Diameter
Maximum Pressure
Maximum Steam Pressure
Material
Price
>
BBFDTEI
4
NPT
64
0.020833"
Raised
1.38"
1.38"
8
0.055556"
Not Rated
Not Rated
Steel
$402.50
BBFDTEC
3/4
NPT
12
0.025000"
Raised
0.75"
0.875000"
4
0.166667"
3,700 psi @ 72° F
3,200 psi @ 300° F
Steel
$121.59
BBFDTEH
3
NPT
48
0.05"
Raised
1.25"
1.25"
8
8"
Not Rated
Not Rated
Steel
$234.52
BBFDTEG
2
NPT
32
0.062500"
Raised
0.875000"
1"
8
6.5"
3,700 psi @ 72° F
3,200 psi @ 300° F
Steel
$122.79
BBFDTED
1
NPT
16
0.175000"
Raised
0.875000"
1"
4
4"
3,700 psi @ 72° F
3,200 psi @ 300° F
Steel
$120.28
BBFDTEB
1/2
NPT
08
0.187500"
Raised
0.75"
0.875000"
4
3.25"
3,700 psi @ 72° F
3,200 psi @ 300° F
Steel
$117.41
BBFDTEE
1 1/4
NPT
20
6.25"
Raised
0.875000"
1"
4
0.093750"
3,700 psi @ 72° F
3,200 psi @ 300° F
Steel
$173.11
BBFDTEF
1 1/2
NPT
24
7"
Raised
1"
1.125000"
4
0.218750"
3,700 psi @ 72° F
3,200 psi @ 300° F
Steel
$129.00
