Two-Piece Thread-ClampingLocknuts for Extreme Vibration
8 Products
Two-Piece Thread-ClampingLocknuts for Extreme Vibration
These locknuts include a two-piece clamp that expands to grip the bolt on all sides and a concave jam nut that clamps the threads onto the bolt for added vibration resistance. They're also known as drake-style nuts.
Part Number
Thread Size
Thread Type
Width
Height
Material
Price
>
Part Number
Thread Size
Thread Type
Width
Height
Material
Price
>
JAGCDABJA
1/2"-20
UNF
0.75"
0.640625"
Steel
$13.12
JAGCDABFA
1/4"-28
UNF
0.437500"
0.375000"
Steel
$11.04
JAGCDACBA
3/4"-16
UNF
1.125000"
0.046875"
Steel
$17.98
JAGCDABHA
3/8"-24
UNF
0.562500"
0.515625"
Steel
$12.00
JAGCDABGA
5/16"-24
UNF
0.5"
0.453125"
Steel
$11.15
JAGCDACAA
5/8"-18
UNF
0.937500"
0.859375"
Steel
$16.15
JAGCDABIA
7/16"-20
UNF
0.687500"
0.593750"
Steel
$13.82
JAGCDACCA
7/8"-14
UNF
1.312500"
0.203125"
Steel
$19.14
