SC-114RG Thrust Ball Bearing
/
SC-114RG-1015
SC-114RG-1015
$0.00
/Each
Bulk orders will be discounted, please contact our sales for a bulk quote.
We will ship your order via FedEx within 3-5 working days after you complete the payment and the related information will be sent to your email.
Searching for the best price?
Complete the inquiry form, and we'll provide you with the most suitable solution.
Request a Quote
Need bulk industrial price?
Submit your volume requirements, and we'll provide a tailored quote for your scale.
BULK INQUIRY REQUEST
YOUR INQUIRY LIST
!
Please add at least one product before submit.
QUOTE SUMMARY
Overview |
|
| Part Number | SC-114RG-1015 |
Characteristics |
|
| System of Measurement | Inch |
| Bearing Type | Ball |
| For Load Direction | Thrust |
| Ball Qty | 5 |
Dimensions |
|
| Outer Dia | 1.938" |
| Outer Dia Tolerance | 0'' to -0.005'' |
| Height | 1.313" |
| Height Tolerance | -0.005'' to +0.005'' |
| Ball Dia | 0.625" |
Material |
|
| Washer Material | 52100 Chrome Steel |
| Ball Material | Chrome Steel |
Performance |
|
| Dynamic Thrust Load(5 RPM) | 9140lbf |
| Dynamic Thrust Load(25 RPM) | 5630lbf |
| Dynamic Thrust Load(50 RPM) | 4570lbf |
| Dynamic Thrust Load(100 RPM) | 3710lbf |
| Dynamic Thrust Load(300 RPM) | 2665lbf |
| Dynamic Thrust Load(500 RPM) | 2285lbf |
| Dynamic Thrust Load(1000 RPM) | 1855lbf |
| Dynamic Thrust Load(1500 RPM) | 1645lbf |
| Static Thrust Load | 17451 lbf |
| Temperature Range | -30° to 110°C |
Properties |
|
| Lubrication | Required |
| RoHS | Compliant |
| REACH | Compliant |
| Weight | 0.92 lbs |
