EADHNBBE
Part Number | EADHNBBE |
System of Measurement | Metric |
Gear Type | Worm |
Component | Gear |
Bore Type | Round |
Module | 0.5 |
Speed Ratio | 15:1 |
Number Of Teeth | 30 |
Pressure Angle | 20° |
Gear Pitch Diameter | 15 mm |
For Number Of Thread Starts | 2 |
OD | 16 mm |
Face Width | 5 mm |
Overall Width | 12 mm |
For Shaft Diameter | 4 mm |
Material | Plastic |
Fabrication | Molded |
Color | White |
Hub Diameter | 12 mm |
Hub Width | 7 mm |
For Thread Direction | Right Hand |
Heat Treatment | Tooth Surface Induction Hardening |
Gear Hardness | 45-55HRC |
Gear Accuracy | ANSI-2 AGMA-11 |
RoHs | RoHS 3 (2015/863/EU) Compliant |
REACH | REACH (EC 1907/2006) (06/25/2020, 209 SVHC) Compliant |
Application Field | Mechanical transmission in chemical, textile machinery, food processing, instrumentation, petroleum and other industries, etc. |
INTERCHANGE
The LILY bearing part series EADHNBBE is a potential replacement for these common bearing part numbers.
LILY
MCMASTER
EADHNBBE
