Tungsten Carbide Balls 24 mm G10
Per Pack of 10
Bulk orders will be discounted, please contact our sales for a bulk quote.We will ship your order via FedEx within 3-5 working days after you complete the payment and the related information will be sent to your email.
Searching for the best price?
Complete the inquiry form, and we'll provide you with the most suitable solution.
Need bulk industrial price?
Submit your volume requirements, and we'll provide a tailored quote for your scale.
| Part Number | Tungsten Carbide Balls 24 mm G10 |
| System of Measurement | Metric |
| Construction | Solid |
| Shape | Ball |
| Appearance | Plain |
| Ball Diameter | 24 mm |
| Ball Dia Tolerance | -0.0025mm to 0.0025mm |
| Ball Grade | G10 |
| Material | C2 Tungsten Carbide |
| Density | 0.54 lbs./cu. in. |
| Sphericity | 0.0025 mm |
| Hardness | Rockwell C75 |
| Tungsten Carbide | 90-94% |
| Cobalt | 6-10% |
| Iron | 0-4% |
| RoHS | Compliant |
| REACH | Compliant |
Design Features of Tungsten Carbide Balls 24 mm G10
Tungsten Carbide Balls 24 mm G10 is designed for exceptional hardness and wear resistance, making it suitable for the most demanding applications. Tungsten Carbide Balls 24 mm G10 ball diameter is 24 mm. Its ball dia tolerance is -0.0025mm to 0.0025mm. It offers superior dimensional stability and strength, ensuring reliable performance in harsh environments and high-stress conditions.
What Benefits Can Tungsten Carbide Balls 24 mm G10 Provide?
- Extreme Rockwell C75: Offers superior resistance to wear, deformation, and scratching, extending service life.
- High Strength: Can withstand high pressures and heavy loads without compromising performance.
- Dimensional Stability: Maintains its shape and size even under extreme temperatures or mechanical stress.
- Corrosion Resistance: Resistant to corrosion, making it suitable for harsh chemical and high-moisture environments.
- Precision and Accuracy: Provides high dimensional accuracy, making it ideal for precision applications.
What Can Tungsten Carbide Balls 24 mm G10 Be Used for?
- Bearings: Used in precision bearings, particularly in industries requiring high wear resistance and load-bearing capacity, such as aerospace and automotive.
- Valves and Pumps: Employed in high-pressure valve systems, hydraulic pumps, and other fluid control systems for their durability and resistance to corrosion.
- Ball Screws: Found in ball screws for precise motion control in machinery and robotics.
- Cutting Tools: Used in tools for high-precision machining due to its hardness and resistance to wear.
- Measuring Instruments: Used in precision measuring instruments, such as gauges and calipers, for accurate measurements under extreme conditions.
