MKP60B
Price $ 317.50
Number
| Part Number | MKP60B |
| Standard Reference | MS27642-S-60S |
| System of Measurement | Inch |
| Bore Dia | 3.75" |
| Bore Dia Tolerance | -0.0010" to 0" |
| Outer Dia | 4.6875" |
| Outer Dia Tolerance | -0.0010" to 0" |
| Ring Width Outer Height | 0.469" |
| Ring Width Outer Height Tolerance | -0.005" to 0" |
| Ring Width Inner Width | 0.531" |
| Ring Width Inner Width Tolerance | -0.0025" to 0" |
| Ball Complement No | 53 |
| Ball Complement Dia | 1/4" |
| Ring Shoulder Outer | 4.505" |
| Ring Shoulder Inner | 3.987" |
| Ring Chamfer Outer | 0.039" |
| Ring Chamfer Outer Tolerance | 0" to 0.015" |
| Ring Chamfer Inner | 0.039" |
| Ring Chamfer Inner Tolerance | 0" to 0.015" |
| Radial Internal Clearance | 0.0001" to 0.0005" |
| Static Radial Load | 33100 lbs |
| Static Thrust Load | 14600 lbs |
| Dynamic Radial Ring Inner Load | 8290 lbs |
| Dynamic Radial Ring Outer Load | 8010 lbs |
| Max Starting Torque | (4) oz-in |
| Weight | 0.74 lbs |
