Timken Spherical Roller Bearings
/
Spherical Roller Bearing Metric and Inch Accessories
/
Inch Accessories - Locknut and Lockwasher
/
AN 26-W 26
AN 26-W 26
$0.00
/Each
Bulk orders will be discounted, please contact our sales for a bulk quote.
We will ship your order via FedEx within 3-5 working days after you complete the payment and the related information will be sent to your email.
Searching for the best price?
Complete the inquiry form, and we'll provide you with the most suitable solution.
Request a Quote
Need bulk industrial price?
Submit your volume requirements, and we'll provide a tailored quote for your scale.
BULK INQUIRY REQUEST
YOUR INQUIRY LIST
!
Please add at least one product before submit.
QUOTE SUMMARY
| Part Number | AN 26-W 26 |
| System of Measurement | Metric |
| Material | Steel |
| Bearing Bore | 130 mm |
| Locknut | AN 26 |
| Lockwasher | W 26 |
| Major Diameter | 129.69 mm |
| Threads No. Per Inch | 12 |
| Relief Diameter A | 126.57 mm |
| Diameter S-3 | 125.41 mm |
| Slot Width (W) | 4.37 mm |
| Length (L) | 21.44 mm |
| Profundity (H) | 4.8 mm |
| Breadth (S) | 12.7 mm |
| Length Of Side (M) | 7.92 mm |
| Outside Diameter (C1) | 171.58 mm |
| Thick (D) | 22.48 mm |
| Material Thickness (Q) | 2.92 mm |
| Inside Diameter (R) | 131.85 mm |
| Outside Diameter (B) | 178.59 mm |
| Inner Tooth Width (s) | 11.05 mm |
