39 1091 01
| Part Number | 39 1091 01 |
Brand: LILY  | |
Equivalent: ROLLIX |
| System of Measurement | Metric |
| Series | rectangular sections |
| Gear | Without Gear |
| Type | Ball |
| Bearing Type | Standard |
| Product Type | Slewing Beraing |
| Inside Diameter Of Inner Ring | 1022 mm |
| Outside Diameter Of Outer Ring | 1166 mm |
| Height Of Overall Bearing Assembly | 56 mm |
| Height Of Inner Ring | 46 mm |
| Height Of Outer Ring | 46 mm |
| Bolt Circle In Inner Ring | 1048 mm |
| Bolt Circle In Outer Ring | 1140 mm |
| Size Holes In Inner Ring | ref. Drawing |
| Size Holes In Outer Ring | ref. Drawing |
| Number Holes In Inner Ring | 48 |
| Number Holes In Outer Ring | 48 |
| Ring Material | 42CRO or 50MN |
| Ball Materrial | Chrome Steel |
| Cage Material | Nylon or 300 Series Stainless Steel |
| Seal Material | NBR |
| RoHS | Compliant |
| Weight | 78 Kg |
})
INTERCHANGE
The LILY bearing part series 39 1091 01 is a potential replacement for these common bearing part numbers.
LILY
ROLLIX
L39 1091 01
39 1091 01
