33 0741 01
Part Number | 33 0741 01 |
Brand: LILY | |
Equivalent: ROLLIX |
System of Measurement | Metric |
Series | rectangular sections |
Gear | Without Gear |
Type | Ball |
Bearing Type | Standard |
Product Type | Slewing Beraing |
Inside Diameter Of Inner Ring | 26.457" |
Outside Diameter Of Outer Ring | 32.126" |
Height Of Overall Bearing Assembly | 2.205" |
Height Of Inner Ring | 1.811" |
Height Of Outer Ring | 1.811" |
Bolt Circle In Inner Ring | 27.48" |
Bolt Circle In Outer Ring | 31.102" |
Size Holes In Inner Ring | ref. Drawing |
Size Holes In Outer Ring | ref. Drawing |
Number Holes In Inner Ring | 40 |
Number Holes In Outer Ring | 40 |
Ring Material | 42CRO or 50MN |
Ball Materrial | Chrome Steel |
Cage Material | Nylon or 300 Series Stainless Steel |
Seal Material | NBR |
RoHS | Compliant |
Weight | 52 Kg |
INTERCHANGE
The LILY bearing part series 33 0741 01 is a potential replacement for these common bearing part numbers.
LILY
ROLLIX
L33 0741 01
33 0741 01
