25 0941 01 Four Point Contact Ball Slewing Ring Bearing
Part Number 25 0941 01
Brand: LILY
|
Equivalent: ROLLIX
System of Measurement Metric
Series light profile
Gear Internal Gear
Type Ball
Bearing Type Flanged
Product Type Slewing Beraing
Inside Diameter Of Inner Ring 840 mm
Outside Diameter Of Outer Ring 1048 mm
External Diameter On Outer Ring 984 mm
Height Of Overall Bearing Assembly 56 mm
Height Of Inner Ring 46 mm
Height Of Outer Ring 46 mm
Bolt Circle In Inner Ring 905 mm
Bolt Circle In Outer Ring 1020 mm
Size Holes In Inner Ring ref. Drawing
Size Holes In Outer Ring ref. Drawing
Number Holes In Inner Ring 22
Number Holes In Outer Ring 16
Pitch Diameter Of Gear 856 mm
Module 8
Number Of Gear Teeth 107
Tooth Form Droite
Ring Material 42CRO or 50MN
Ball Materrial Chrome Steel
Cage Material Nylon or 300 Series Stainless Steel
Seal Material NBR
RoHS Compliant
Weight 71 Kg

Request a Quote

*
*
*
Allow file formats (gif、jpeg、jpg、png、pdf、txt、doc、xls、xlsx、docx)
INTERCHANGE
The LILY bearing part series 25 0941 01 is a potential replacement for these common bearing part numbers.
LILY
ROLLIX
L25 0941 01
25 0941 01
