22 0841 01 Four Point Contact Ball Slewing Ring Bearing
Part Number 22 0841 01
Brand: LILY
|
Equivalent: ROLLIX
System of Measurement Metric
Series light profile
Gear Internal Gear
Type Ball
Bearing Type Flanged
Product Type Slewing Beraing
Inside Diameter Of Inner Ring 736 mm
Outside Diameter Of Outer Ring 948 mm
External Diameter On Outer Ring 884 mm
Height Of Overall Bearing Assembly 56 mm
Height Of Inner Ring 46 mm
Height Of Outer Ring 46 mm
Bolt Circle In Inner Ring 805 mm
Bolt Circle In Outer Ring 920 mm
Size Holes In Inner Ring ref. Drawing
Size Holes In Outer Ring ref. Drawing
Number Holes In Inner Ring 20
Number Holes In Outer Ring 14
Pitch Diameter Of Gear 752 mm
Module 8
Number Of Gear Teeth 94
Tooth Form Droite
Ring Material 42CRO or 50MN
Ball Materrial Chrome Steel
Cage Material Nylon or 300 Series Stainless Steel
Seal Material NBR
RoHS Compliant
Weight 63 Kg

Request a Quote

*
*
*
Allow file formats (gif、jpeg、jpg、png、pdf、txt、doc、xls、xlsx、docx)
INTERCHANGE
The LILY bearing part series 22 0841 01 is a potential replacement for these common bearing part numbers.
LILY
ROLLIX
L22 0841 01
22 0841 01
