121.50.5600.990.41.1502
| Part Number | 121.50.5600.990.41.1502 |
Brand: LILY  | |
Equivalent: ROTHEERDE |
| System of Measurement | Metric |
| Series | Series 12 |
| Gear | External Gear |
| Type | Roller |
| Bearing Type | Standard |
| Product Type | Slewing Beraing |
| Inside Diameter Of Inner Ring | 5342 mm |
| Outside Diameter Of Outer Ring | 5923.2 mm |
| Internal Diameter On Outer Ring | 5540 mm |
| External Diameter On Inner Ring | 5668 mm |
| Height Of Overall Bearing Assembly | 221 mm |
| Height Of Inner Ring | 205 mm |
| Height Of Outer Ring | 156 mm |
| Bolt Size | 36 mm |
| Bolt Circle In Inner Ring | 5420 mm |
| Bolt Circle In Outer Ring | 5730 mm |
| Size Holes In Inner Ring | 39 mm |
| Size Holes In Outer Ring | 39 mm |
| Number Holes In Inner Ring | 90 |
| Number Holes In Outer Ring | 90 |
| Pitch Diameter Of Gear | 5856 mm |
| Module | 24 |
| Number Of Gear Teeth | 244 |
| Permissible Tooth Forces T | 73237.5 lbs |
| Max Gear Tooth Load Fz | 146475 lbs |
| Correspond | FIG1 |
| Tooth Width | 156 mm |
| Ring Material | 42CRO or 50MN |
| Ball Materrial | Chrome Steel |
| Cage Material | Nylon or 300 Series Stainless Steel |
| Seal Material | NBR |
| RoHS | Compliant |
| Weight | 6397 Kg |
| Diameter Of Bearing Raceway | 5600 mm |
| Distance Between Bottom Outer Ring/Inner Ring | 16 mm |
| Distance at top Outer Ring/Inner Ring | 65 mm |
| Number Of Grease Nipples | 18 |
})
INTERCHANGE
The LILY bearing part series 121.50.5600.990.41.1502 is a potential replacement for these common bearing part numbers.
LILY
ROTHEERDE
L121.50.5600.990.41.1502
121.50.5600.990.41.1502
