120Q12H
Bulk orders will be discounted, please contact our sales for a bulk quote.
We will ship your order via FedEx within 3-5 working days after you complete the payment and the related information will be sent to your email.
Searching for the best price?
Complete the inquiry form, and we'll provide you with the most suitable solution.
Need bulk industrial price?
Submit your volume requirements, and we'll provide a tailored quote for your scale.
Overview |
|
| Part Number | 120Q12H |
Brand: LILY  |
Interchangeable With: Martin |
Characteristics |
|
| System of Measurement | Inch |
| Number Of Teeth | 12 |
| For Roller Chain Trade Size | 120 |
| Type | 4 |
| Bushing Size | Q1 |
Dimensions |
|
| Pitch Diameter | 5.796" |
| OD | 6.5" |
| Bore Max | 2.6875" |
| Chain Pitch | 1.5" |
| Dimensions T | 0.924" |
| Dimensions L | 2.5" |
| Dimensions OL | 2.3906" |
| Dimensions H | 4.125" |
| Dimensions P | 1.5625" |
Material |
|
| Material | Steel |
Properties |
|
| WT.lb(APPROX) With Hub | 9.8 lbs |
| WT.lb(APPROX) Rim Only | 6.3 lbs |
Design Features of 120Q12H Sprockets
Heavy-Duty Construction: Features a large 1.500-inch (38.10 mm) pitch for handling extreme loads in demanding applications.ANSI Standard Compliance: Manufactured to meet ANSI specifications for full compatibility with standard sprockets and equipment. High-Strength Steels: Made from heat-treated steel for exceptional durability and wear resistance. Precision Manufacturing: Rollers and bushings are accurately machined to reduce friction and ensure smooth operation.
What Benefits Can 120Q12H Sprockets Provide?
- Exceptional Load Capacity: Designed to handle extremely heavy loads with its robust 1.500-inch pitch.
- Extended Service Life: Heat-treated steel construction offers outstanding durability and resistance to wear.
- Efficient Power Transmission: Precision-machined rollers and bushings reduce friction for smoother, more efficient operation.
- Seamless Compatibility: Built to ANSI standards for easy integration with standard sprockets and industrial setups.
What Can 120Q12H Sprockets Be Used for?
- Heavy-Duty Industrial Machinery: Ideal for driving large-scale equipment that requires high torque and strength.
- High-Capacity Conveyor Systems: Suitable for moving heavy loads in manufacturing and material handling operations.
- Agricultural Equipment: Used in robust farm machinery designed for tough working environments.
- Construction and Mining Equipment: Applicable in cranes, hoists, and other machinery that operates under extreme loads.
