Slewing Ring Bearings

07 0673 00 Slewing Ring Bearings

LILY Interchangeable From Rollix
07 0673 00 Slewing Ring Bearings
Price Not yet
Specifications
Part Number 07 0673 00
Gear Internal gear
Geometry
External Diameter (DR) 771
Internal Diameter (di) 541
Height(H) 70
Weight(kg) 96
Gear Data
Pitch Diameter of Gear (D2) 552
Module(m) 6
Number of teeth(z) 91
Pressure Angle of Gear Teeth (?) 20
Tooth Form Droite
Mounting Holes
Bolt Circle in Outer Ring (Lo) 736
Number Holes in Outer Ring (no) 32
Bolt Circle in Inner Ring (Li) 610
Number Holes in Inner Ring (ni) 32
MEASUREMENTS IN MILLIMETERS
MAXIMUM DEFLECTION
MAXIMUM MEASUREMENT IN 1 POINT
07 0673 00 Slewing Ring Bearings
