07 0489 11
| Part Number | 07 0489 11 |
Brand: LILY  | |
Equivalent: ROLLIX |
| System of Measurement | Metric |
| Series | cross roller |
| Gear | Internal Gear |
| Type | Roller |
| Bearing Type | Standard |
| Product Type | Slewing Beraing |
| Inside Diameter Of Inner Ring | 385 mm |
| Outside Diameter Of Outer Ring | 562 mm |
| Height Of Overall Bearing Assembly | 60 mm |
| Height Of Inner Ring | 50 mm |
| Height Of Outer Ring | 50 mm |
| Bolt Circle In Inner Ring | 440 mm |
| Bolt Circle In Outer Ring | 538 mm |
| Size Holes In Inner Ring | ref. Drawing |
| Size Holes In Outer Ring | ref. Drawing |
| Number Holes In Inner Ring | 30 |
| Number Holes In Outer Ring | 30 |
| Pitch Diameter Of Gear | 396 mm |
| Module | 6 |
| Number Of Gear Teeth | 66 |
| Tooth Form | Droite |
| Ring Material | 42CRO or 50MN |
| Ball Materrial | Chrome Steel |
| Cage Material | Nylon or 300 Series Stainless Steel |
| Seal Material | NBR |
| RoHS | Compliant |
| Weight | 44 Kg |
})
INTERCHANGE
The LILY bearing part series 07 0489 11 is a potential replacement for these common bearing part numbers.
LILY
ROLLIX
L07 0489 11
07 0489 11
