03 0980 02
| Part Number | 03 0980 02 |
Brand: LILY  | |
Equivalent: ROLLIX |
| System of Measurement | Metric |
| Series | rectangular sections |
| Gear | Without Gear |
| Type | Ball |
| Bearing Type | Standard |
| Product Type | Slewing Beraing |
| Inside Diameter Of Inner Ring | 845 mm |
| Outside Diameter Of Outer Ring | 1130 mm |
| Height Of Overall Bearing Assembly | 100 mm |
| Height Of Inner Ring | 90 mm |
| Height Of Outer Ring | 90 mm |
| Bolt Circle In Inner Ring | 890 mm |
| Bolt Circle In Outer Ring | 1070 mm |
| Size Holes In Inner Ring | ref. Drawing |
| Size Holes In Outer Ring | ref. Drawing |
| Number Holes In Inner Ring | 36 |
| Number Holes In Outer Ring | 36 |
| Ring Material | 42CRO or 50MN |
| Ball Materrial | Chrome Steel |
| Cage Material | Nylon or 300 Series Stainless Steel |
| Seal Material | NBR |
| RoHS | Compliant |
| Weight | 271 Kg |
})
INTERCHANGE
The LILY bearing part series 03 0980 02 is a potential replacement for these common bearing part numbers.
LILY
ROLLIX
L03 0980 02
03 0980 02
