03 0785 00 Four Point Contact Ball Slewing Ring Bearing
Part Number 03 0785 00
Brand: LILY
|
Equivalent: ROLLIX
System of Measurement Metric
Series rectangular sections
Gear Without Gear
Type Ball
Bearing Type Standard
Product Type Slewing Beraing
Inside Diameter Of Inner Ring 670 mm
Outside Diameter Of Outer Ring 900 mm
Height Of Overall Bearing Assembly 86 mm
Height Of Inner Ring 77 mm
Height Of Outer Ring 77 mm
Bolt Circle In Inner Ring 710 mm
Bolt Circle In Outer Ring 860 mm
Size Holes In Inner Ring ref. Drawing
Size Holes In Outer Ring ref. Drawing
Number Holes In Inner Ring 36
Number Holes In Outer Ring 36
Ring Material 42CRO or 50MN
Ball Materrial Chrome Steel
Cage Material Nylon or 300 Series Stainless Steel
Seal Material NBR
RoHS Compliant
Weight 148 Kg

Request a Quote

*
*
*
Allow file formats (gif、jpeg、jpg、png、pdf、txt、doc、xls、xlsx、docx)
INTERCHANGE
The LILY bearing part series 03 0785 00 is a potential replacement for these common bearing part numbers.
LILY
ROLLIX
L03 0785 00
03 0785 00
