02 0520 00 Slewing Ring Bearings

LILY Interchangeable From Rollix
02 0520 00 Slewing Ring Bearings
Price Not yet
Specifications
Part Number 02 0520 00
Gear Internal gear
Geometry
External Diameter (DR) 610
Internal Diameter (di) 403
Height(H) 68
Weight(kg) 63
Gear Data
Pitch Diameter of Gear (D2) 414
Module(m) 6
Number of teeth(z) 68
Pressure Angle of Gear Teeth (?) 20
Tooth Form Droite
Mounting Holes
Bolt Circle in Outer Ring (Lo) 574
Number Holes in Outer Ring (no) 24
Bolt Circle in Inner Ring (Li) 466
Number Holes in Inner Ring (ni) 24
MEASUREMENTS IN MILLIMETERS
MAXIMUM DEFLECTION
MAXIMUM MEASUREMENT IN 1 POINT
