02 0308 01

02 0308 01 Four Point Contact Ball Slewing Ring Bearing
Part Number 02 0308 01
Brand: LILY
|
Equivalent: ROLLIX
System of Measurement Metric
Series rectangular sections
Gear Internal Gear
Type Ball
Bearing Type Standard
Product Type Slewing Beraing
Inside Diameter Of Inner Ring 217 mm
Outside Diameter Of Outer Ring 385 mm
Height Of Overall Bearing Assembly 55 mm
Height Of Inner Ring 45 mm
Height Of Outer Ring 45 mm
Bolt Circle In Inner Ring 259 mm
Bolt Circle In Outer Ring 358 mm
Size Holes In Inner Ring ref. Drawing
Size Holes In Outer Ring ref. Drawing
Number Holes In Inner Ring 24
Number Holes In Outer Ring 24
Pitch Diameter Of Gear 224 mm
Module 4
Number Of Gear Teeth 56
Tooth Form Droite
Ring Material 42CRO or 50MN
Ball Materrial Chrome Steel
Cage Material Nylon or 300 Series Stainless Steel
Seal Material NBR
RoHS Compliant
Weight 24 Kg

Request a Quote

*
*
*
Allow file formats (gif、jpeg、jpg、png、pdf、txt、doc、xls、xlsx、docx)
INTERCHANGE
The LILY bearing part series 02 0308 01 is a potential replacement for these common bearing part numbers.
LILY
ROLLIX
L02 0308 01
02 0308 01
