01 0880 00
Part Number | 01 0880 00 |
Brand: LILY | |
Equivalent: ROLLIX |
System of Measurement | Metric |
Series | rectangular sections |
Gear | External Gear |
Type | Ball |
Bearing Type | Standard |
Product Type | Slewing Beraing |
Inside Diameter Of Inner Ring | 770 mm |
Outside Diameter Of Outer Ring | 1022 mm |
Height Of Overall Bearing Assembly | 82 mm |
Height Of Inner Ring | 66 mm |
Height Of Outer Ring | 72 mm |
Bolt Circle In Inner Ring | 815 mm |
Bolt Circle In Outer Ring | 945 mm |
Size Holes In Inner Ring | ref. Drawing |
Size Holes In Outer Ring | ref. Drawing |
Number Holes In Inner Ring | 36 |
Number Holes In Outer Ring | 36 |
Pitch Diameter Of Gear | 1008 mm |
Module | 8 |
Number Of Gear Teeth | 125 |
Tooth Form | Droite |
Ring Material | 42CRO or 50MN |
Ball Materrial | Chrome Steel |
Cage Material | Nylon or 300 Series Stainless Steel |
Seal Material | NBR |
RoHS | Compliant |
Weight | 159 Kg |
INTERCHANGE
The LILY bearing part series 01 0880 00 is a potential replacement for these common bearing part numbers.
LILY
ROLLIX
L01 0880 00
01 0880 00
