01 0626 00
| Part Number | 01 0626 00 |
Brand: LILY  | |
Equivalent: ROLLIX |
| System of Measurement | Metric |
| Series | rectangular sections |
| Gear | External Gear |
| Type | Ball |
| Bearing Type | Standard |
| Product Type | Slewing Beraing |
| Inside Diameter Of Inner Ring | 20.315" |
| Outside Diameter Of Outer Ring | 30.472" |
| Height Of Overall Bearing Assembly | 3.228" |
| Height Of Inner Ring | 2.598" |
| Height Of Outer Ring | 2.835" |
| Bolt Circle In Inner Ring | 22.047" |
| Bolt Circle In Outer Ring | 27.244" |
| Size Holes In Inner Ring | ref. Drawing |
| Size Holes In Outer Ring | ref. Drawing |
| Number Holes In Inner Ring | 24 |
| Number Holes In Outer Ring | 24 |
| Pitch Diameter Of Gear | 29.921" |
| Module | 8 |
| Number Of Gear Teeth | 94 |
| Tooth Form | Droite |
| Ring Material | 42CRO or 50MN |
| Ball Materrial | Chrome Steel |
| Cage Material | Nylon or 300 Series Stainless Steel |
| Seal Material | NBR |
| RoHS | Compliant |
| Weight | 118 Kg |
})
INTERCHANGE
The LILY bearing part series 01 0626 00 is a potential replacement for these common bearing part numbers.
LILY
ROLLIX
L01 0626 00
01 0626 00
