Food Industry Linear Sleeve Bearings for Support Rail Shafts
7 Products
Food Industry Linear Sleeve Bearings for Support Rail Shafts
Made of FDA-listed materials for use in food applications, these bearings also have excellent chemical and corrosion resistance.
Part Number
Bore Dia
Outer Dia
Overall
Length
Length
Retaining Ring Groove
End-to End Lg.
End-to End Lg.
With End
Seals
Seals
Dynamic Radial
Load
Load
Static Radial
Load
Load
Temperature
Range
Range
GGHGKHB
0.376"
5/8"
7/8"
0.642"
No
30 lbs @ 100 fpm
325 lbs
-400° to 375° F
GGHGKHC
0.501"
7/8"
1 1/4"
0.969"
No
60 lbs @ 100 fpm
625 lbs
-400° to 375° F
GGHGKHE
0.751"
1 1/4"
1 5/8"
1.178"
No
100 lbs @ 100 fpm
1200 lbs
-400° to 375° F
GGHGKHF
1.001"
1 9/16"
2 1/4"
1.765"
No
200 lbs @ 100 fpm
2200 lbs
-400° to 375° F
GGHGKHG
12.038 mm
22 mm
32 mm
20 mm
No
60 lbs @ 100 fpm
590 lbs
-400° to 375° F
GGHGKHH
16.038 mm
26 mm
36 mm
22mm
No
90 lbs @ 100 fpm
890 lbs
-400° to 375° F
GGHGKHI
20.047 mm
32 mm
45 mm
28mm
No
130 lbs @ 100 fpm
1350 lbs
-400° to 375° F
