Notes:
1. Rings and balls are manufactured from premium quality AISI 52100 chrome steel.
2. Operating temperature range:-65 to +250 °F.
3. All bearings include removable PTFE seals.
4. Bearings are lubricated with MIL-PRF-81322 grease, 80% minimum fill,unless otherwise specified.
5. External surfaces (except bore)are cadmium plated per AMS-QQ-P-416. All dimensions apply after plating.
6. Custom sizes, materials, tolerances,radial internal clearances, lubrication, plating, etc., are available upon request.
7. All dimensions are in inches, unless otherwise specified.
KP-B
Extra Light Duty, Single Row
Part Number
Standard Reference
Bore Dia
Outer Dia
Ring Width Outer Height
Ring Width Inner Width
Static Radial Load
Static Thrust Load
Dynamic Radial Ring Inner Load
Dynamic Radial Ring Outer Load
Price
>
Part Number
Standard Reference
Bore Dia
Outer Dia
Ring Width Outer Height
Ring Width Inner Width
Static Radial Load
Static Thrust Load
Dynamic Radial Ring Inner Load
Dynamic Radial Ring Outer Load
Price
>
KP16B
MS27642-16
1"
1.75"
0.375"
0.437"
8085 lbf
3600 lbf
4260 lbf
3960 lbf
$112.00
KP21B
MS27642-21
1.313"
2.0625"
0.375"
0.437"
9840 lbf
4400 lbf
4590 lbf
4290 lbf
$126.50
KP23B
MS27642-23
1.438"
2.1875"
0.375"
0.437"
10500 lbf
4700 lbf
4650 lbf
4360 lbf
$157.00
KP25B
MS27642-25
1.563"
2.3125"
0.375"
0.437"
11300 lbf
5000 lbf
4680 lbf
4420 lbf
$160.00
KP29B
MS27642-29
1.813"
2.5625"
0.375"
0.437"
12700 lbf
5600 lbf
4760 lbf
4530 lbf
$172.00
KP33B
MS27642-33
2.063"
2.8125"
0.375"
0.437"
14400 lbf
6400 lbf
4820 lbf
4630 lbf
$214.50
KP37B
MS27642-37
2.313"
3.0625"
0.375"
0.437"
15800 lbf
7000 lbf
4880 lbf
4690 lbf
$242.00
KP47B
MS27642-47
2.938"
3.875"
0.469"
0.531"
24700 lbf
10900 lbf
6600 lbf
6390 lbf
$267.00
KP49B
MS27642-49
3.063"
4"
0.469"
0.531"
27500 lbf
12100 lbf
8150 lbf
7840 lbf
$293.50
KP52B
MS27642-52
3.25"
4.1875"
0.469"
0.531"
28700 lbf
12600 lbf
8210 lbf
7880 lbf
$311.50
KP56B
MS27642-56
3.5"
4.4375"
0.469"
0.531"
31200 lbf
13700 lbf
8240 lbf
7970 lbf
$337.00
KP60B
MS27642-60
3.75"
4.6875"
0.469"
0.531"
33100 lbf
14600 lbf
8290 lbf
8010 lbf
$379.50
KP64B
MS27642-64
4"
4.9375"
0.469"
0.531"
35000 lbf
15400 lbf
8350 lbf
8100 lbf
$396.00
KP68B
MS27642-68
4.25"
5.3125"
0.531"
0.593"
41900 lbf
18400 lbf
10280 lbf
9900 lbf
$421.00
KP72B
MS27642-72
4.5"
5.5625"
0.531"
0.593"
44300 lbf
19500 lbf
10330 lbf
10000 lbf
$448.00
KP76B
MS27642-76
4.75"
5.8125"
0.531"
0.593"
46700 lbf
20500 lbf
10350 lbf
10050 lbf
$478.50
KP80B
MS27642-80
5"
6.0625"
0.531"
0.593"
48200 lbf
21200 lbf
10360 lbf
10090 lbf
$525.50
KP84B
MS27642-84
5.25"
6.3125"
0.531"
0.593"
50600 lbf
22300 lbf
10420 lbf
10120 lbf
$564.00
