DW-K/DW-
6 Products
More
Notes:
1. Rings and balls are manufactured from premium quality AISI 52100 chrome steel.
2. Operating temperature range:-65 to +250 °F.
3. All bearings include nonremovable PTFE seals.
4. Bearings are lubricated with MIL-PRF-81322 grease, 80% minimum fill,unless otherwise specified.
5. Contact angles are convergent(‘/ ').
6. External surfaces (except bore)are cadmium plated per AMS-QQ-P-416. All dimensions apply after plating.
7. Custom sizes, materials, tolerances,radial internal clearances, lubrication, plating, etc., are available upon request.
8. All dimensions are in inches, unless otherwise specified.
DW-K/DW-
Extra Wide, Double Row, Intermediate Duty
Part Number
Standard Reference
Bore Dia
Outer Dia
Ring Width Outer Height
Ring Width Inner Width
Static Radial Load
Static Thrust Load
Dynamic Radial Ring Inner Load
Dynamic Radial Ring Outer Load
Price
>
Part Number
Standard Reference
Bore Dia
Outer Dia
Ring Width Outer Height
Ring Width Inner Width
Static Radial Load
Static Thrust Load
Dynamic Radial Ring Inner Load
Dynamic Radial Ring Outer Load
Price
>
DW4K2
MS27647-4A
0.25"
0.625"
0.5"
0.562"
1400 lbf
500 lbf
1050 lbf
960 lbf
$137.50
DW4
-
0.25"
0.75"
0.75"
0.875"
3750 lbf
1240 lbf
2650 lbf
2300 lbf
$137.50
DW4K
MS27647-4
0.25"
0.75"
0.75"
0.875"
2770 lbf
900 lbf
2070 lbf
1850 lbf
$137.50
DW5
MS27647-5
0.3125"
0.875"
0.813"
0.938"
5140 lbf
1600 lbf
2600 lbf
2320 lbf
$152.50
DW6
MS27647-6
0.375"
1.0625"
1.063"
1.188"
8440 lbf
2600 lbf
4220 lbf
3740 lbf
$180.50
DW8
MS27647-8
0.5"
1.4375"
1.375"
1.5"
15520 lbf
4700 lbf
7610 lbf
6520 lbf
$213.00
