DSP- / MDSP-
12 Products
More
Notes:
1. Rings and balls are manufactured from premium quality AISI 52100 chrome steel.
2. Operating temperature range:-65 to +250 °F.
3. All bearings include nonremovable PTFE seals.
4. Bearings are lubricated with MIL-PRF-81322 grease, 80% minimum fill,unless otherwise specified.
5. External surfaces (except bore) are cadmium plated per AMS-QQ-P-416.All dimensions apply after plating.
6. Custom sizes, materials, tolerances,radial internal clearances, lubrication, plating, etc., are available upon request.
7. All dimensions are in inches, unless otherwise specified.
DSP- / MDSP-
Self-Aligning, Double Row, Heavy Duty
Part Number
Standard Reference
Bore Dia
Outer Dia
Ring Width Outer Height
Ring Width Inner Width
Static Radial Load
Static Thrust Load
Dynamic Radial Ring Inner Load
Dynamic Radial Ring Outer Load
Price
>
Part Number
Standard Reference
Bore Dia
Outer Dia
Ring Width Outer Height
Ring Width Inner Width
Static Radial Load
Static Thrust Load
Dynamic Radial Ring Inner Load
Dynamic Radial Ring Outer Load
Price
>
MDSP3
-
0.19"
0.7774"
0.392"
0.5"
1420 lbf
200 lbf
1420 lbf
1220 lbf
$153.50
DSP3
MS27643-3
0.19"
0.7774"
0.392"
0.5"
1420 lbf
200 lbf
1420 lbf
1220 lbf
$153.50
DSP4
MS27643-4
0.25"
0.9014"
0.464"
0.687"
1780 lbf
300 lbf
1780 lbf
1600 lbf
$178.50
MDSP4
-
0.25"
0.9014"
0.464"
0.687"
1780 lbf
300 lbf
1780 lbf
1600 lbf
$178.50
DSP5
MS27643-5
0.3125"
1.25"
0.656"
0.812"
3740 lbf
600 lbf
3740 lbf
3300 lbf
$229.50
MDSP5
-
0.3125"
1.25"
0.656"
0.812"
3740 lbf
600 lbf
3740 lbf
3300 lbf
$229.50
MDSP6
-
0.375"
1.4375"
0.75"
0.937"
5100 lbf
800 lbf
4980 lbf
4370 lbf
$241.50
DSP6
MS27643-6
0.375"
1.4375"
0.75"
0.937"
5100 lbf
800 lbf
4980 lbf
4370 lbf
$241.50
DSP8
MS27643-8
0.5"
1.6875"
0.812"
1"
7120 lbf
1000 lbf
6340 lbf
5570 lbf
$337.50
MDSP8
-
0.5"
1.6875"
0.812"
1"
7120 lbf
1000 lbf
6340 lbf
5570 lbf
$337.50
DSP10
MS27643-10
0.625"
1.9375"
0.937"
1.125"
9000 lbf
1300 lbf
7780 lbf
6860 lbf
$392.50
MDSP10
-
0.625"
1.9375"
0.937"
1.125"
9000 lbf
1300 lbf
7780 lbf
6860 lbf
$392.50
