Notes:
1. Rings and balls are manufactured from premium quality AISI 440C stainless steel.
2. Operating temperature range:-65 to +250 °F.
3. All bearings include nonremovable PTFE seals.
4. Bearings are lubricated with MIL-PRF-81322 grease, 80% minimum fill,unless otherwise specified.
6. Custom sizes, materials, tolerances,radial internal clearances, lubrication, plating, etc., are available upon request.
8. All dimensions are in inches, unless otherwise specified.
SSW-AK
Intermediate Duty, Single Row, Stainless Steel
Part Number
Standard Reference
Bore Dia
Outer Dia
Ring Width Outer Height
Ring Width Inner Width
Static Radial Load
Static Thrust Load
Dynamic Radial Ring Inner Load
Dynamic Radial Ring Outer Load
Price
>
Part Number
Standard Reference
Bore Dia
Outer Dia
Ring Width Outer Height
Ring Width Inner Width
Static Radial Load
Static Thrust Load
Dynamic Radial Ring Inner Load
Dynamic Radial Ring Outer Load
Price
>
SSW3AK
MS27649-3
0.19"
0.625"
0.312"
0.406"
450 lbf
210 lbf
440 lbf
440 lbf
$56.00
SSW4AK
MS27649-4
0.25"
0.75"
0.312"
0.438"
525 lbf
250 lbf
510 lbf
510 lbf
$72.50
SSW5AK
MS27649-5
0.3125"
0.8125"
0.344"
0.469"
820 lbf
380 lbf
800 lbf
800 lbf
$91.00
SSW6AK
MS27649-6
0.375"
0.875"
0.344"
0.469"
820 lbf
380 lbf
800 lbf
800 lbf
$106.50
SSW8AK
MS27649-8
0.5"
1.125"
0.438"
0.562"
1350 lbf
630 lbf
1310 lbf
1310 lbf
$125.50
SSW10AK
MS27649-10
0.625"
1.375"
0.469"
0.594"
1840 lbf
860 lbf
1790 lbf
1790 lbf
$153.50
SSW12AK
MS27649-12
0.75"
1.625"
0.531"
0.656"
2400 lbf
1120 lbf
2340 lbf
2340 lbf
$162.00
SSW16AK
MS27649-16
1"
2"
0.562"
0.688"
3000 lbf
1400 lbf
2920 lbf
2920 lbf
$184.00
SSW20AK
MS27649-20
1.25"
2.25"
0.562"
0.688"
3600 lbf
1680 lbf
3500 lbf
3270 lbf
$197.00
