GFCJKGJ
| Part Number | GFCJKGJ |
| System of Measurement | Metric |
| Gear Type | Miter |
| Component | Gear |
| Bore Type | Round |
| Module | 3 |
| Speed Ratio | 1:1 |
| Number Of Teeth | 20 |
| For Shaft Angle | 120° |
| Pressure Angle | 20° |
| Gear Pitch Diameter | 60 mm |
| OD | 63 mm |
| Face Width | 10 mm |
| Overall Width | 39.4 mm |
| For Shaft Diameter | 16 mm |
| Mounting Distance | 50 mm |
| Material | Steel |
| Teeth Heat Treatment | Not Hardened |
| Hub Diameter | 50 mm |
| Hub Width | 24 mm |
| Heat Treatment | Tooth Surface Induction Hardening |
| Gear Hardness | 45-55HRC |
| Gear Accuracy | ANSI-2 AGMA-11 |
| RoHs | RoHS 3 (2015/863/EU) Compliant |
| REACH | REACH (EC 1907/2006) (06/25/2020, 209 SVHC) Compliant |
| Application Field | Mechanical transmission in chemical, textile machinery, food processing, instrumentation, petroleum and other industries, etc. |
})
INTERCHANGE
The LILY bearing part series GFCJKGJ is a potential replacement for these common bearing part numbers.
LILY
MCMASTER
GFCJKGJ
