GAEFFKFB
Price $ 50.77
| Part Number | GAEFFKFB |
| System of Measurement | Inch |
| Gear Type | Spur |
| Pressure Angle | 14 1/2° |
| Component | Gear |
| Bore Type | Round/Machinable |
| Gear Pitch | 12 |
| Number Of Teeth | 48 |
| Gear Pitch Diameter | 4" |
| OD | 4.17" |
| Face Width | 3/4" |
| Overall Width | 1.5" |
| For Shaft Diameter | 1/2"-1 3/8" |
| Material | Nylon Plastic |
| Fabrication | Machined |
| Color | White |
| Hub Diameter | 2.5" |
| Hub Width | 0.75" |
| RoHS | RoHS 3 (2015/863/EU) Compliant |
| REACH | Not Compliant |
INTERCHANGE
The LILY bearing part series GAEFFKFB is a potential replacement for these common bearing part numbers.
LILY
MCMASTER
GAEFFKFB
