GABANBG
Price $ 31.02
| Part Number | GABANBG |
| System of Measurement | Metric |
| Gear Type | Spiral Bevel |
| Component | Gear |
| Bore Type | Machinable/Round |
| Face Width | 6 mm |
| Pressure Angle | 20° |
| Speed Ratio | 2:1 |
| Module | 1 |
| Number Of Teeth | 40 |
| Gear Pitch Diameter | 40 mm |
| OD | 40.52 mm |
| Overall Width | 15 mm |
| For Shaft Diameter | 8-18 mm |
| Mounting Distance (A) | 22 mm |
| Material | Black-Oxide 1045 Carbon Steel |
| Teeth Heat Treatment | Hardened |
| Teeth Fabrication | Not Ground |
| Hub Diameter | 25 mm |
| Hub Width | 8 mm |
| RoHS | RoHS 3 (2015/863/EU) Compliant |
| REACH | REACH (EC 1907/2006) (07/08/2021, 219 SVHC) Compliant |
})
INTERCHANGE
The LILY bearing part series GABANBG is a potential replacement for these common bearing part numbers.
LILY
MCMASTER
GABANBG
