34 0941 01
Part Number | 34 0941 01 |
Brand: LILY | |
Equivalent: ROLLIX |
System of Measurement | Metric |
Series | rectangular sections |
Gear | External Gear |
Type | Ball |
Bearing Type | Standard |
Product Type | Slewing Beraing |
Inside Diameter Of Inner Ring | 34.331" |
Outside Diameter Of Outer Ring | 41.181" |
Height Of Overall Bearing Assembly | 2.205" |
Height Of Inner Ring | 1.811" |
Height Of Outer Ring | 1.811" |
Bolt Circle In Inner Ring | 35.354" |
Bolt Circle In Outer Ring | 38.78" |
Size Holes In Inner Ring | ref. Drawing |
Size Holes In Outer Ring | ref. Drawing |
Number Holes In Inner Ring | 44 |
Number Holes In Outer Ring | 40 |
Pitch Diameter Of Gear | 40.63" |
Module | 8 |
Number Of Gear Teeth | 129 |
Tooth Form | Droite |
Ring Material | 42CRO or 50MN |
Ball Materrial | Chrome Steel |
Cage Material | Nylon or 300 Series Stainless Steel |
Seal Material | NBR |
RoHS | Compliant |
Weight | 78 Kg |
INTERCHANGE
The LILY bearing part series 34 0941 01 is a potential replacement for these common bearing part numbers.
LILY
ROLLIX
L34 0941 01
34 0941 01
