6365K405 Chemical-Resistant Dry-Running Sleeve Bearings
Part Number 6365K405
System of Measurement Inch
Bearing Type Plain
Plain Bearing Type Sleeve
For Load Direction Radial
For Shaft Diameter 5/8"
Bore Dia 0.627"
Bore Dia Tolerance 0" to 0.002"
For Housing ID 7/8"
Outer Dia 0.8755"
Outer Dia Tolerance 0" to 0.001"
Length 3/4"
Length Tolerance -0.01" to 0.01"
Dynamic Radial Load 3750 lbf
Static Radial Load 3750 lbf
Max Speed (X1000 rpm) 0.06
Backing Material Fiberglass
Material PTFE Plastic
Lubrication Not Required
For Shaft Type Round
Shaft Mount Type Slip Fit
Temperature Range -55° to 280° F
RoHS Compliant
REACH Compliant

Request a Quote

Allow file formats (gif、jpeg、jpg、png、pdf、txt、doc、xls、xlsx、docx)
The LILY bearing part series 6365K405 is a potential replacement for these common bearing part numbers.
