6365K405
| Part Number | 6365K405 |
| System of Measurement | Inch |
| Bearing Type | Plain |
| Plain Bearing Type | Sleeve |
| For Load Direction | Radial |
| For Shaft Diameter | 5/8" |
| Bore Dia | 0.627" |
| Bore Dia Tolerance | 0" to 0.002" |
| For Housing ID | 7/8" |
| Outer Dia | 0.8755" |
| Outer Dia Tolerance | 0" to 0.001" |
| Length | 3/4" |
| Length Tolerance | -0.01" to 0.01" |
| Dynamic Radial Load | 3750 lbf |
| Static Radial Load | 3750 lbf |
| Max Speed (X1000 rpm) | 0.06 |
| Backing Material | Fiberglass |
| Material | PTFE Plastic |
| Lubrication | Not Required |
| For Shaft Type | Round |
| Shaft Mount Type | Slip Fit |
| Temperature Range | -55° to 280° F |
| RoHS | Compliant |
| REACH | Compliant |
})
INTERCHANGE
The LILY bearing part series 6365K405 is a potential replacement for these common bearing part numbers.
LILY
MCMASTER
L6365K405
6365K405
